Steering Tube Pressure Aluminum Die Casting with Power Painted (DC091)

Prod Model:	DC091
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Usage:	Electronic Accessories
Die Casting Machine Type:	Hot Chamber Die Casting Machine
Proessing:	Machining Center
Chamber Structure:	Horizontal
Materail:	Aluminum

Product Description

Our service: 1. High Quality system control and good service. 2. Advanced equipment and excellent R&D Team. 3. Highly skilled manufacturing process. 4. Excellent smooth surface finish, we have good surface treatment Brother Company which cooperate with us over 8 years old. Welcome to send us your product drawings for quotation. Small quantity order is acceptable. We pay attention to your inquiry, and take quotation as our important work. Die and component material and hardness for various cast metals Die component Cast metal Tin, lead & zinc Aluminium & magnesium Copper & brass Material Hardness Material Hardness Material Hardness Cavity inserts P20 [note 1] 290–330  HB H13 42–48  HRC DIN 1.2367 38–44 HRC H11 46–50 HRC H11 42–48 HRC H20, H21, H22 44–48 HRC H13 46–50 HRC Cores H13 46–52 HRC H13 44–48 HRC DIN 1.2367 40–46 HRC DIN 1.2367 42–48 HRC Core pins H13 48–52 HRC DIN 1.2367  prehard 37–40 HRC DIN 1.2367 prehard 37–40 HRC Sprue parts H13 48–52 HRC H13 DIN 1.2367 46–48 HRC 44–46 HRC DIN 1.2367 42–46 HRC Nozzle 420 40–44 HRC H13 42–48 HRC DIN 1.2367 H13 40–44 HRC 42–48 HRC Ejector pins H13 [note 2] 46–50 HRC H13 [note 2] 46–50 HRC H13 [note 2] 46–50 HRC Plunger shot sleeve H13 [note 2] 46–50 HRC H13 [note 2] DIN 1.2367 [note 2] 42–48 HRC 42–48 HRC DIN 1.2367 [note 2] H13 [note 2] 42–46 HRC 42–46 HRC Holder block 4140 prehard ~300 HB 4140 prehard ~300 HB 4140 prehard ~300 HB
