| Price: | US $ 0.01-0.02/Piece |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 500/Piece |
| Pay Type: | L/C,T/T,D/P,Paypal,Money Gram |
| Table 5: |
| Close die forging | |
| 1) Suitable for: | big bath & medium size |
| 2) Commonly used materials |
1) Wind power shaft:42CrMo4V, 34CrNiMo6,Wind power flange: S355, C22, 16Mn, 20Mn, 42CrMo, F304 2) Forged pipe fittings: SA106 CL B, SA 106 CL C, WB36, 12Cr1MoV, SA 335 P11, P12, P22, P91, SA182 Gr. F1, Gr. F5, Gr. F11 CL2, Gr. F12 CL2, Gr. F22 CL3, SA350 Gr. LF1, Gr. LF2, Gr. LF3, 3) Pressure vessel forgings: SA105, SA350 LF2, 16Mn, 20MnMo, 15MnMo, 12Cr2Mo1, 14Cr1Mo, F304, F316,17-4PH 4) Shaft related forgings: 25CrMo4, 42CrMo4, 40CrNiMo, 34CrNi3Mo, 25Cr2Ni4MoV, 18CrNiMo5, 30CrMo, 4130,4140 5) Gear related forgings:35CrMo, 34CrMo4, 4137, 42CrMo, 4140, SCM440, 20CrMnMo, 40CrNiMo, 20CrNi2Mo, 20Cr2Ni4A, 34CrNi3Mo |
| 3) Industry involved: | Automotive industry/Engineering/^. |
| 4) Part overall dimension limit: |
max 4000tons Hot die forging press: up to 2500tons Electronic hydraulic hammer: up to 5tons |
| 5) Representative product: | Auto connecting rods/Steering engines/Gears/Driving shafts/Vehicle axles |
| 6) Manufacturer Certification: | ISO9001 (2000)/TS16949 |
| 7)feature |
Precision forging hammers range from 160 tons till 4000 tons -Precision CNC machining centers for further machining process -Induction furnace for raw material heating -Heat treatment of continuous quench + temper +carburization available |
| 8)Annual forging capacit | 8000toms |
| 9)the unit weight of forgings | range from 0.1kg/pc till 200kg/pc |
| 10)Mold development ability | According to the customer's drawing or sample. |
| Name & Description | Forging Handling Capacities | Quantity |
| 6000 Tons Free Forging Press | Max. Single Forging in 45 Tons | 1 |
| 5000mm Diameter Rolling Forging Machine | Max. Single Forging in 16 Tons | 1 |
| 800 Tons Free Forging Press | Max. Single Forging in 7.5 Tons | 1 |
| 60 Tons Forging Handling Operator | Max. Single Forging in 45 Tons | 1 |
| 10 Tons Forging Handling Operator | Max. Single Forging in 7.5 Tons | 1 |
| 80 Tons Crane | Max. Single Ingot in 80 Tons | 1 |
| 60/30 Tons Crane | Max. Single Ingot in 60 Tons | 1 |
| 30/10 Tons Crane | 30/10 Tons | 5 |
| Trolley Heat Furnace | 5000*1500*1200 mm | 3 |
| Trolley Heat Furnace | 8000*2000*1600 mm | 3 |
| Trolley Heat Furnace | 6500*1500*1200 mm | 4 |
| Vertical Heat Furnac | Ø2500*10000 mm | 2 |
| Total Forging Equipment Quantity | 24 | |
| Prod Model: | CF051 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| QC Control: | 100% Inspection on Critical Dimensions |
| Cost Control: | Most Efficient Production Process Design |
| Pressure Supply Type: | Atmospheric Pressure |
| Structure: | Horizontal |
| Riveting Principle: | Radial Models(',JM Series) |
