M42 High Speed Steel (DIN 1.3247, SKH59, T11342)

M42 High Speed Steel (DIN 1.3247, SKH59, T11342)
Price: US $ 500-5000/Ton
Trade Terms: FOB,CFR,EXW
Min Order: 1/Ton
Pay Type: L/C,T/T
Prod Model: M42
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Similar Grades: DIN 1.3247, Skh59, T11342
Size Range: Diameter: 20-480mm
Delivery Condition: Annealed, Qunched and Tempered
Surface Condition: Annealed, Qunched and Tempered
Quality Standard: ASTM -A600
Type: Alloy Steel Bar
Standard: ASTM
Composition: Ferrous Steel Scrap
Special Use: Mold Steel
Application: Structural Steel Bar
Steel Grade: High Quality Steel
Technique: Hot Rolled, Forged
Shape: Round, Square, Flat
Surface Treatment: Black, Grinded, Peeled, Polished, Rough Turned

Product Description

Similar Grades:
DIN 1.3247,SKH59,T11342

Shape:
Round, Flat, Square.

Size Range:
 Diameter(mm)Thickness (mm)Width (mm)Length(mm)
Round20-480--2000-5800
Square20-480--2000-5800
flat-20-5080-6002000-5800


Steel-making Condition:
EF, EF/EAF+LF+VD, EF/EAF+ESR

Delivery Condition:
Annealed , Quenched + Tempered

Surface Condition:
Black, Grinded, Peeled, Rough turned, Polished

Features:
1.Competitive price
2.Immediate delivery
3.Premium quality
4.Reliable service
5.MOQ: 1 Ton

Packing detailsIn seaworthy packing, as your requirement.
Delivery detailswithin 30-50 days


Chemical Composition:

C
MnPSSiCrNiMoVWCoCu
1.05-1.150.15-0.400.030max0.030max0.15-0.653.50-4.250.3max9.00-10.00.95-1.351.15-1.857.75-8.750.25max


Heat Treatment:
Heat treatment temperatures, including rate of heating, cooling and soaking times will vary due to factors such as the shape and size of each M42 high speed steel component. Other considerations during the heat treatment process include the type of furnace, quenching medium and work piece transfer facilities.
Forging: Pre heat the M42 high speed steel slowly and uniformly to 650-760°C and equalise. Then increase more quickly to the forging temperature of 1010-1150°C and equalise prior to forging. Do not allow the forging temperature to drop below 980°C, if this occurs re heating will be necessary. Always cool the high speed steel very slowly after forging.
Annealing: Annealing of M42 high speed steel is recommended after hot working and before rehardening. Heat the M42 high speed steel to 850°C at a rate of no more than 220°C per hour. Always hold at temperature for one hour per 25mm of thickness (with two hours being minimum). Furnace cool slowly. The M42 high speed steel annealed hardness achieved should be 269 Brinell or lower.
Stress Relieving: If tools produced from M42 high speed steel are heavily machined or ground it is recommended to stress relieve after machining and prior to hardening to minimise the possibility of distortion. To stress relieve heat the component to 600-650°C and soak well (approximately two hours) Cool slowly in the furnace. The M42 high speed steel tools can be finish machined before heat treatment.
Hardening: For best results harden in a vacuum or controlled furnace, or in a properly rectified salt bath. Pre heat thoroughly in two steps to 450-500°C, then to 820-870°C, transfer to the high temperature salt bath or furnace. The exact hardening temperature to use for M35 will depend on the type of work being treated, but in general components should be hardened from the range of 1050-1250°C.
Tempering: For best results harden the M42 high speed steel in a vacuum or controlled furnace, or in a properly rectified salt bath. Pre-heat the steel thoroughly to 820-870°C then transfer to the high temperature salt bath or furnace. The exact hardening temperature to use for M42 high speed steel will depend on the type of work being treated, but in general components should be hardened from the range of 1160-1180°C in salt, or 1180-1190°C in atmosphere or vacuum furnaces. After a short hold at the hardening temperature, quench the component without further soaking into salt at 540-595°C or warm oil. If salt quenched allow the component to equalise at the bath temperature and then complete the quench in still air.
Temperature [°C] 500 550 600
Hardness [HRc] 67 69 63

Introduction:
M42 high speed steel is a premium cobalt high speed steel with a chemical composition designed for high hardness and superior hot hardness. These properties make the steel an excellent choice for machining high-strength and pre-hardened steels, high-hardness alloys, and the difficult-to-machine, nonferrous super alloys used in the aerospace, oil, and power generation industries.
M42 high speed steel exhibits excellent wear resistance by virtue of high heat-treated hardness (68 to 70 HRC), and the high cobalt content imparts the hot hardness. As such, the cutting edges on tools made from M42 high speed steel stay sharp and hard in heavy-duty and high-production cutting applications.

Applications:
M42 high speed steel can be used in conditions where the demand for hot hardness is important. Commonly used for cutting tools including twist drills, taps, broaches tools, milling cutters, reamers, end mills, bandsaw blades, cold work tools, and thread rolling dies.
Contact Information:
FUSHUN SPECIAL STEEL CO., LTD.
Tel: 89-0731-89903933(CHANGSHA, Office)
Fax: +86-0731-89853933
Mobile: +86-18773142293
Website: www.fushunspecialsteel.com




To expand the international market and get the advantages of markets in Hong Kong, We, FUSHUN SPECIAL STEEL Co., Ltd, were established by Huangshi Chengquan Group in 2014.

Huangshi Chengquan Group consists of the following parts:

Ezhou Liufan Chengquan Forging & Casting Factory, established in 1995, covers an area of 10000 square meters. The production capacity is more than 10000 tons per year.

Foshan Shiyong Tool Steel Sales Co., Ltd. Founded in 1998, covers an area of 3000 square meters, annual inventory of 15000 tons.

Provide with the following services: Saw Cutting, Mold, Machining.

Based on its manufacturing capacity, We, Fushun Special Steel Co., Ltd., are engaged in the import and export of iron alloy steel and other special steel.

Export:

Our own products:

Tool Steel: (carbon tool steel, alloy tool steel, high-speed tool steel),

Die steel: (cold work die steel, hot work die steel, plastic die steel)

And sale: Structural steel(carbon structural steel, alloy structural steel)

Shape: Round, square, flat, heavy thickness plate, heavy wall thickness steel tube.

Stainless steel, Bearing steel, Spring steel, Cold Heading Steel, Forgings

Imports: Ferroalloy (chromium iron, nickel iron, vanadium iron, molybdenum iron, etc. )

To provide high quality services for global customers, We insist in the follow principles:

Best price: Try our best to give the lowest price

Top quality: Fake a penalty ten

Fast delivery: Timely delivery

One stop shop: With 20 year business experience, we know steel sources in China, and we can provide a one stop shop service.

After service: Responsive, quality objection don't shuffle.
