| Price: | Negotiable/Set |
|---|---|
| Trade Terms: | FOB,CFR,EXW |
| Min Order: | 1/Set |
| Pay Type: | L/C,T/T |
A, Technical parameter:
1. Machine specification: Forming thickness(0.5-0.6)xL, yield strength≤G250Mpa
2. Forming speed: 12-15M/min (EXCLUDING CUTTING STOP TIME)
3. Forming roller: About 24 groups
4. Main motor power: 7.5KW
5. Hydraulic station power: 4KW
6. Roller material: 45# forged steel, surface coated with chrome
7. Main shaft material: 45# steel
8. Main axis dia.: 68mm
9. Hydraulic cutting pressure: 10-12Mpa
10. Cutting method: Hydraulic powered, cutting after roll forming.
11. Cutting blade material: Cr12 quenching treatment
12. Electrical controlling system: Whole line adopted PLC control, cut to length tolerance≤2mm
B, Roll forming line comprised equipment
YX76 DOWNPIPE ROLL FORMING MACHINCE comprised of 3T manual uncoiler, main drive, infeed guiding, roll forming machine, tighten device, cutting equipment, hydraulic system, electrical controlling system, output table.
C, Flow Chart
Uncoiling Infeed Guiding Roll forming Tighten Hydraulic cutting Run-out table
Goods Delivery
Our Honorable Prize
Transportation
All goods will be shipped to your country, containers number will be decided with how many machines would you choose
Installation of the machine
The individual components of the machine are installed according to the layout and prepared for the commissioning.
The installation comprises of:
- Installation by Suhang service technicians.
- The following services are included:
- Installation of the machine components.
- Adjustment of the machine components.
- Connection of all motors to the control cabinet.
- Installation of the required safety devices.
Delivery extent does not comprise of:
- Media supply (electrics, etc. )to the machine(control cabinet)
- Raw material, process material
- Raw material for test
- Transport and lifting devices
- Auxiliary staff.
The operators of the plant should be present during the installation in order to become familiar with the new machines.
| Prod Model: | RF-RP |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Voltage: | 380V |
| Power(W): | 13kw |
| Control System: | PLC with Touch Screen |
| Machine Running: | Smoothly and Steadily |
| Material Thickness: | 0.3-0.8mm |
| Forging Forming Method: | Mold Forging |
| Certification: | ISO Certificate |
| Warranty: | 1 Year |
