EPS/Rock Wool/Mineral Wool Sandwich Panel Machine (AF-S960)

EPS/Rock Wool/Mineral Wool Sandwich Panel Machine (AF-S960)
Price: US $ 32000/Piece
Trade Terms: FOB,CFR,EXW
Min Order: 1/Piece
Pay Type: L/C,T/T
Prod Model: AF-S960
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Name: EPS/Rock Wool/Mineral Wool Sandwich Panel Machine
Machine Color: as Require
Machine Size: 27m*2.5m*3m
Machine Weight: 20t
Size Of Container: 2* 40gp
Control System: PLC
Cutting Type: Hydraulic
Driven Type: Chain
Usage: Roof and Wall
Life Long: 10year
Forging Forming Method: Mold Forging

Product Description

Summary

Features of EPS Sandwich Panel Production Line:
1. Various wall panel production available (tong & groove, various joint refrigerator panel).
2. Corrugated panel with various option available.
3. EPS or rock wool & glass wool panel available.
4. Joint-hidden panel plate with various joint and plate type available.
5. SingleContinuous automatic production available.
6. Nonstandard panel type for Customer requirement.
7. Flexible option for customer practical need.
8. Automatic length to cut and count available.
9. Complete accessory equipment available.

Features of EPS Panels
1. Energy saving
You can save air-conditioning and heating expenses remarkably, thanks to its excellent insulation effect as mush as 4.2 times of cement brick.

2. Perfectly insulated and waterproof
Using the high-density EPS, it is moisture and noise free.

3. Semi-permanence and easy installation
Using galvanized steel sheets treated with fluorine and silicone on the surface, it is unchangeable and semi-permanent. Due to the standardized products, you can save the cost for construction by hiring the least number of workers and minimizing the period of construction.

4. Excellent lightness and firmness
It is light but firm, so even a house is simply built, it is strong enough. Coating with different material, you can enjoy various type of panels.

Specifications:

Power supply: AC380/50-60Hz
Total power: 32KW
Production line speed: 4-8m/min
Main specification

T o t a l mot o r power


32KW


Processing speed


4-6 m/min(adjustable)


The thickness of upper steel plate


0.3-0.8mm


The feeding width of upper steel plate


1000/1200/1250mm


The thickness of lower steel plate


0.3-0.8mm


The feeding width of lower steel plate


1000/1200/1250mm


Voltage


380V/50-60HZ


The material inside


EPS/Rock wool


The panel  thickness


50-300mm


The width of stocket board


950/1150mm


We mainly supply high quality roll forming machine. We have achieved good performance up to now, sincerely welcome businessmen overseas to establish a long-term cooperation to create a beautiful tomorrow!
Our factory mainly produce all kinds of roll forming machine, for example, rofo sheet roll forming machine, c purlin roll forming machine, glazed tile roll forming machine, deck floor roll forming machine, sandwich panel production line and so on.
Our factory is established form 2010, up to now, we have sold machines to Canada, Bolivia, South Africa, Dubai, India, Russia and many other countries,
Hope we can cooperate happily
