C Channel Cold Roll Forming Machinery (AF-C80-300)

C Channel Cold Roll Forming Machinery (AF-C80-300)
Price: US $ 32000/Piece
Trade Terms: FOB,CFR,EXW
Min Order: 1/Piece
Pay Type: T/T
Prod Model: AF-C80-300
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Name: C Channel Cold Roll Forming Machinery
Machine Color: as Require
Machine Size: 13m*1.2m*1.4m
Machine Weight: 6tons
Control System: PLC
Cutting Type: Hydraulic
Driven Type: Chain
Size Of Container: 40gp
Life Long: 10year
Forging Forming Method: Mold Forging

Product Description

C channel cold roll forming machinery

Competitive Advantage:
1. Automatic roll forming machine
2. High quality and comfortable price
3. Well reputation of after sale

Working flow:
De-coiling------leveling-----Roll forming-------Punching-----Cutting-----Run Out Table

Machine components:
1. Un-coiler
2. Entry Guide + Five(5)-Roll Leveler
3. Roll forming uint
4. Cantilever Type Adjustable Roll Former
5. Punching device
6. Cutting device
7. Run Out Table
8. Electric control system
9. Hydraulic station
                                                                   Technical Description
Items  spc.  Qty
Decoiler (1)Max. Width: 500 mm
(2)Inner Diameter: Φ350 – Φ400 mm
(3)Out Diameter: 1500 mm
(4)Max. Loading Capacity: 3000 kgs
 1set
Leleving device (1)Max. Width: 500 mm
(2)Thickness: 1-3 mm
(3)Rollers for Leveling: 5 rollers
(4)Material for Rollers: GCr15 steel
(5)Hardness for Heat Treatment: HRC55 – 60
 1set
Roll forming device (1)Rolled Material: Cold Rolled Steel Sheet
(2)Material Thickness: 1-3 mm
(3)Rollers: 13Groups
(4)Material for Rollers: GCr15 steel
(5)Material for shaft: GCr15 steel
(6) Hardness for Heat Treatment: HRC55 – 60
(7)Diameter of shaft: 80mm
(8)Frame panel thickness: 16mm
(9)Bottom frame: 36# H-section steel
(10)Motor Power: 15 kw
(11)Speed Reducer Model: QZ 400
(12)Rolling Speed: 2 – 8 m / min; Adjustable
(13)Driven type: 2"Chain
 1set
Punching device (1)Adopted with 4 pillars hydraulic punches.
(2)Length for Punch Table: 6 m
(3)Motor for Hydraulic Punch: 7.5 kw
 1set
Cutting device (1)Material for Cut-Off Modular:Cr12 steel
(2)Hardness for Heat Treatment:HRC59 – 61
(3)Cut-Off Type:Hydraulic, Automatic Cut-Off
(4)Cut-Off Modular:1 set
(5)Motor for Hydraulic Stand: 7.5 kw
 1set
 Electrical system (1) Type: PLC Frequency Control System with touch screen
(2) PLC Brand: Japan Panasonic
(3) Encoder Brand: Omron
(4)Length Error:±1mm
(5) Transducer: Panasonic
 1set

We mainly supply high quality roll forming machine. We have achieved good performance up to now, sincerely welcome businessmen overseas to establish a long-term cooperation to create a beautiful tomorrow!
Our factory mainly produce all kinds of roll forming machine, for example, rofo sheet roll forming machine, c purlin roll forming machine, glazed tile roll forming machine, deck floor roll forming machine, sandwich panel production line and so on.
Our factory is established form 2010, up to now, we have sold machines to Canada, Bolivia, South Africa, Dubai, India, Russia and many other countries,
Hope we can cooperate happily
