Wall Panel Roll Forming Machine
Main Features of Wall Panel Roll Forming Machine:
Zhongji Wall panel roll forming machine, adopting roll forming method, can produce beautiful appearance, strong panels which are extensively used in wall construction or outdoor decoration. This type machine possesses advance and innovative technology that can provide convenient roller change. This type can be equipped with PLC control and touch screen.
Technological Process of Wall Panel Roll Forming Machine:
Uncoiling---Feeding---Leveling---Punching---Rool Forming---Cutting---Products Collecting
Main Technical Specifications of Wall Panel Roll Forming Machine:
Number Items Unit\Type RF-WP
1 Steel Thickness mm 0.4-0.8
2 Forming Speed m/min 8-18
3 Roller stands stand 20
4 Roller Material 45# steel, coated with chrome
5 Main Motor Power Kw 5.5
6 Hydraulic cutting Power Kw 2.2
7 Hydraulic pressure Mpa 10-12
8 Power Supply 380V, 50Hz, 3 phase
9 Tolerance mm 1.5
10 Material of cutting Cr12
11 Control system PLC with touch screen
12 Machine net weight T 12
