TF Building, Storage Use Steel Plank Roll Forming Line

TF building, storage use C60-250 steel plank roll forming line



TF building, storage use C60-250 steel plank roll forming line main specification
1) Thickness: 2.0mm
2) Width of Coil: About 406mm
3) Material: Q235
4) Yield Stress: 235MPa
5) Forming Step: 16 steps
6) Material of Roller: GCr15,
Hardness HRC58-62, Chroming
7) Produce Speed: About 5-6m/min
8) Tolerance: From the end 300mm
Open in tolerance 2mm
9) Power:
Three-phase AC power: 380V(± 10%), 50Hz
10) Environment temperature: -10~40,
Relative humidity: 90%(25)No coagulate frost
11) Floor space: 31m*3.5m

2 TF building, storage use C60-250 steel plank roll forming line equipment composition
A) Un-coiler one set
B) Levele one set
C) Servo-feeder one set
D) Punch Device one set
E) Forming Machine one set
F) Moving Cutter one set
G) Run out Table one set
H) Hydraulic System one set
I) PLC Control System one set

3 The steel plank uses include:

1. Construction Sites
2. Storage shelves
3. Helicopter Landing Pads
4. Irrigation Tracks
5. Launches and boat ramp extensions
6. Corrals and chutes for livestock
7. Warehouse flooring
8. Mobile home moving
9. RV tracks or storage areas
10. Storage platforms for heavy equipment, supplies or runways.



Company brief:

Xinxiang Tianfeng Machinery Manufacture Co. Ltd. Is a twenty years old manufaturer of cold roll forming eauipment, a leading manufacturer for steel plate coiling machinery, cold-bending & rolling steel plate shaping machineries and automatic production lines. The products are mainly used in steel structure industry for producing C&Z type purlin, colored wall and floor protecting steel plate, thermal insulating plate and load-bearing plate of buildings, and other complementary thin wall cold-bending shaped seel plates, expressway railings, colorful decorating and protecting steel plates for high-grade steel stucture residendces.
