- No. Of Work Station...18-20stations
- Max. Width of Coil...1094-1250mm
- Min. Width of Coil...1000mm
- Max. Thickness of Coil...0.8mm
- Min. Thickness of Coil...0.35mm
- Max. Roll shafts Dia...76mm
- Line Speed...18-40mtr. /min.
- Required Motor Capacity...26K. W
- Overall L x W x H (Approx. )...13M*2.2M*1.8M
- Roller material: GCR15 quenched 58° -62° , chromed
- Decelerating motor: BWD14-43-55KW
- Outside is cast iron, surface needed polish and paint. Inside is 60# forge and press metal)
- Transducer: Panasonic
- Cages...Use the strong steel nets
- Levelling screws on base...With Thick metal paltes
Suzhou Yuan Steel & Machinery Co., Ltd., mainly deals in Roll Forming Machines as the following:
Roll forming machines fabricated to the highest precision to deliver the efficient cold roll forming you need with little waste.
Tile forming machines to fashion your glazed tiles into the shapes you need with precise cutting.
Ridge cap forming machines which shapes steel with repeated accuracy delivering the best of jobs.
Double-deck, roll shutter and down pipe forming machines add to the excellent portfolio available.
Other machines include those for roofing board, C/Z purlin, big span arch and uncoiler, stacker.
Producer lines include floor deck, fast guardrail and colour steel sandwich board.
Tube Mills include high frequency ERW tube (FM16 to FM720 models), stainless welded tube (FM16 to FM660 models) and titanium (FM16 to FM660 models).
Equipment for slitting and flattening series (thickness 0.16 to 0.18mm respectively up to 25mm, width 200mm to 2500mm).
Your specific needs are not here? Do not worry as we can supply these too and that includes your metal product needs.
Suzhou Yuan Steel & Machinery Co., Ltd. Listens to your needs and provides the best solution.
All work is guaranteed and CE certification can be arranged delivery and satisfaction reported from North America, South America, Europe, Middle East, Southeast Asia, Russia, Australia and more.
Give us the chance to meet your needs and you will be satisfied every time you use the machinery.
You are welcome to visit. See the first class fabrication facilities for yourself and discuss your needs face to face. Nearby, conveniently located hotels are excellent and served by modern communications which include nearby airports.
