Technical parameter
1. Main motor power: 3kw
2. Forming speed: 8-10m/min
3. Diameter of roller: 70millimeter
4. Thickness of coil sheet; 0.3-0.8mm
5. The width of the colored sheet: 1000millimeter
6. The effective of steel sheet: 840/900millimeter
7. Hydraulic station pressure: 3 kw
8. Hydraulic pressure: 10-12Mpa
9. Total Weight: 3.5ton
10. Voltage: 380volt
11. Roll stand: 11groups
12. PLC: Computer adopt PLC, Mitsubishi FX-IS series
13. Size length*width*high: 7.0m*1.3m*1.2m
14. Roller material: High grade No. 45 forged steel, plated hard chrome on
The surface of roller with thickness 0.05 millimeter
15. ROTARY ENCODER: OMPON
16. Materialof cutter: Cr12
Service
We provide the technical support for whole life.
Meanwhile, if any parts go broken and not artificial damage, we will send you new ones for free.
When need the technician to go abroad, we will arrange the technician.
But the buyer should take all the cost, including Visa, Roundtrip ticket, suitable accommodation and pay the service fee to the technician with $50/days
Botou xinsheng roll forming machinery factory, dedicated to focus on cold_formed metal plate roll forming equipment and manufactureing, now has a unique mode of management and product development capacity, ranking with the industy-leading level. My plant products due to structural light, design reasonable, constantly updated and greatly favored customers.
My factory is located in the Bohai Sea Economic circle, China foundary city-Botou city, north of Beijing and Tianjin, East Bohai Sea, 104, 106National Road, Beijing-Shanghai Railway, Beijing-Fuzhou Expressway runs through the city, convenient transportation and location.
My factory'main products include: Glazed tile equipment, building equipment contractors board, C/Z shaped steel forming equipment, composite plate molding equipment, automobile car plate, anode plate, such as dust removal equipment, and in accordance with the actual needs of the user-made production. At the same time provide users with pre-sales, after a series of technical guidance, production, installation, repair through-train service.
