Specifications
Metal Stud Roll Forming machine
Mateiral: Chromed steel
Thickness: 0.4-0.8mm
Clients profile can be designed.
Metal Stud Roll Forming machine
1. Technical parameter:
Item Specification
Material Type Pre-painted steel coil & galvanized coils
Thickness 0.4-0.8mm
Yield strength 235-345Mpa
Roller material 45#Chrome steel
Forming speed About 15m/min
Output speed 12m/min
Speed adjusting mode AC Frequency
Roller drive Decelerating motor + Chain drive
Cutting mode Hydraulic cutting
Cutter material Cr12 mould steel
Length measurement Encoder
Control mode Mitsubishi PLC
Operating mode Button + Mitsubishi Touch screen
Main motor power(kw) 4KW
Hydraulic station motor power(kw) 3 KW
2. Components of machine:
Decoiler 1set (3MT capacity)
Feeding & guiding device 1set
Main roll forming machine 1set
Hydraulic cutting system 1set
Controlling system 1set
Run out table 1set
3. Process flow:
Decoiler -- Feeding & Guiding -- Roll forming---Hydraulic Cutting -- product to run out table
As a professional roll forming machinery and related product company, Hangzhou Yutong Machinery Co., Ltd. Has 12 years' experience in R&D and production. The rich practical experience can help us produce the high quality, low cost, high efficiency product.
