Roofing & Tile double layer roll forming machine
Suitable material: Steel sheet and embossed aluminium
Thickness: 0.32mm --- 0.70 mm
Yield Stress: 235Mpa + 50
Coil width: 1200mm
Product Spec:
Roll forming panel: Cover width: 900mm(could design according to your requirement)
Length: Any length
Tile forming panel: Cover width: 950mm(could design according to your requirement)
Step length range: 200350mm
Speed: 12--15 m/min(for roll forming system)
2---3 m/min(for tile forming system)
Power Requirement: Main motor power: 5 Kw
Hydraulic station power: 7.5 Kw
Coil car: Capacity: 5 MT
Moving length: 3000mm
Hydraulic Decoiler Max. Capacity: 5000kgs
ID: 480---520mm
Max OD: 1250mm
Max Sheet Width: 1250mm
Type of cutting: Roll-formed and length-set cutting
Shaft diameter: 75mm
Installation Dimension: About 18000X4000X1500mm
Total weight: About 18500kg
Roller Material: High grade No. 45 forged steel, with digital-controlled procession, Painted with hard chrome
Active Shaft Material: High grade No. 45 carbon wrought steel, which can improve the integrated mechanic feature of the shaft.
Electric Elements: PLC control panel, transducer imported from Mitsubishi. Other elements from famous suppliers in China.
Cutter blade: Cr12 mould steel with quenched treatment.
Hangzhou Jingjing Machinery Co., Ltd. is invested by Hangzhou Yangli Industrial Group Co., Ltd. Products include steel building machinery, steel building engineering projects, steel building material, etc.
As a subsidiary, Hangzhou Jingjing Machinery Co., Ltd is in charge of manufacturing products for group company. Our achievement in the Building Industry is based upon our commitment to quality, reliability, and precision. We are full service facility capable of offering ordinary products or designing them exactly according to customers' detailed requirement. From steel building machinery and steel building engineering projects to steel building material, we will take care of all your needs.
Leaning upon the group, we have great design & manufacturing capacity. We own machinists, not just machine operators applying years of machining expertise and knowledge. So we can ensure the good quality throughout the production process. From the moment the products are designed, until they are finished and shipped to our customers, we can provide quality control information. This makes sure our customers will not delay in their production schedule.
We are ready to build a life long relationship with you as a supplier, a partner and a friend. We look forward to hearing from you at any time!
