Cold room panel machine:
1. High quality
2. Reasonable price
3. Best sales after service
Price: FOB USD 65000~100000 / Set
Minimum Order Quantity: Negotiable Trial Order
Minimum Order Quantity: 1 Set/SetsTrial Order
Shipping Port: Shanghai
Packaging Details: Be suitable for shipping
Delivery Time: 90days
Payment Terms: L/C, T/T
Supply Ability: 15 Set/Sets per Month
Breif Introduction:
BMX cold room panel machine is the equipment developed to produce cabinet, refrigerator panel, Wall and door panel. The most feature of this machine is simultaneously processing punching, bending, And roll forming in one machine, releasing the slow and fussy manual work. With fully automatic, Reliable, easyoperation and convenient panel width adjust; This smaller figure machinehas outstanding Performance as well as cheaper price than others. It is able toproduce various nonstandard size Cabinet panels whatever in large or small scale.
Specification:
External/fix dimensions: 8000mm *1800mm*1900mm
Main power: 7KW (Hydraulic power: 4 or 2.2kw)
Gross Weight: About 6000kg
Forming Speed: 0-8m/min
Board width: 300-1200 mm
Panel thickness: Color steel: 0.3-0.7mm; Stailess0.3-0.5mm
Length of Shortest board: 1500mm
Punch pressure: Hydraulic or Air
Bending(2 sides): 1 side or 2sides
PLC controlled, auto production, Touch screen applied convenient opera
Wuxi Jing Jia International Trade Co., Ltd. is located by the coast of beautiful Tai Lake of the Yangtze River Delta, Wuxi, with Shanghai-Nanjing Railway, Xin-Chang Railway, Beijing-Shanghai Expressway, Shanghai-Nanjing Expressway and Huyi Expressway converging and the Grand Canal (China) passing through, only 100m from National Highway 312. It is a modern technology enterprise integrating R&D, manufacture, technical service and import & export trade. Our tenet is "Build Credit Once, Serve You Forever!
To adapt to the development of domestic and foreign steel structure, the company has been engaged in production of steel structure roofs and wall containment channeled steel plate equipment for years. It is also committed to the R&D of new products. We have developed many series of channeled steel plate production lines from the initial monolayer corrugated sheet pressing production line, such as slitting line production line, series hidden gripping wall roof plate production line, series colorbond sandwiched steel plate production line, series C-type steel and Z-type steel numerical control tape punching and purlin production line, series floor steel bearing plate production line, PU load board production line, series arch roof with or without beam and series production equipment, fully meeting requirements of all steel buildings.
Our company has strong technical strength, high-level management personnel, strong production capacity and complete quality tracking and detection. We have passed the certification of ISO9001: 2000 Quality Management System, and the quality management during production strictly executes 9001 standard. The company has ranked among the industry in China, our users spread all over China and our products are exported to many countries and regions in Southeast Asia, South Africa, America, etc. We have established good cooperative relationship with many manufacturers and distributors, forming wide product marketing channels.
Wuxi Jing Jia International Trade Co., Ltd. will give play to its advantages of technology, market channel and market development capacity to provide professional and excellent service for manufacturers and users at home and abroad.
