Our BMY-5 roll forming machinery:
1. Best quality
2. Reasonable price
3. Beutiful outlook
4. Best after-sales service
Weight: 14ton
Model number: BMY
Brand name: Jingjia
Shipping port: Shanghai
Delivery time: 90days
Price: 150000RMB-1750000RMB
Supply ability: 20sets/month
Packing: Be suitable for shipping
BMY-5 roll forming machinery
Introduction:
BMY-5 quick change C to Z purlin forming machine adopting integrated adjustment with unique Design can provide quick, infinite size change which simplifies the process of it to fulfill The requests of customers. Formed Slash and splay stiffing ribs strengthen the rolled steel Shape. In addition, the parallel adjustable splay ribs can also strengthen it further.
Features
Adopt with advance integrated adjustment equipment that facilitates the change of product specification.
Under the principle of rolling friction, it have the features such as small resisting force and Stable transmission, so Seldom friction heat would be generated.
Punching equipment could automatically punch the hole in middle and edge. Automatically complete the production plan and all kind of job like length Set, Punching, Cutting, with single data input.
Equipped with Slash stiffing rib or splayed stiffing rib.
Specification:
External/fix dimensions: 11400mm × 1600mm × 1800mm
Main engine power: 11KW;
Hydraulic system power: 15KW;
Level engine power: 3KW
Equipment gross weight: About14000kg
Forming Speed /Shape speed: ≤ 12m/min
Width of section (Max): 300 mm
Suppresses the appropriate board thickness: (Q235) 1.6~3.0mm
Hydraulic pressure: 18~20Mpa
Max carry capacity of Coil: 5 Tons
PLC controlled, auto production, Touch screen applied convenient operation
Wuxi Jing Jia International Trade Co., Ltd. is located by the coast of beautiful Tai Lake of the Yangtze River Delta, Wuxi, with Shanghai-Nanjing Railway, Xin-Chang Railway, Beijing-Shanghai Expressway, Shanghai-Nanjing Expressway and Huyi Expressway converging and the Grand Canal (China) passing through, only 100m from National Highway 312. It is a modern technology enterprise integrating R&D, manufacture, technical service and import & export trade. Our tenet is "Build Credit Once, Serve You Forever!
To adapt to the development of domestic and foreign steel structure, the company has been engaged in production of steel structure roofs and wall containment channeled steel plate equipment for years. It is also committed to the R&D of new products. We have developed many series of channeled steel plate production lines from the initial monolayer corrugated sheet pressing production line, such as slitting line production line, series hidden gripping wall roof plate production line, series colorbond sandwiched steel plate production line, series C-type steel and Z-type steel numerical control tape punching and purlin production line, series floor steel bearing plate production line, PU load board production line, series arch roof with or without beam and series production equipment, fully meeting requirements of all steel buildings.
Our company has strong technical strength, high-level management personnel, strong production capacity and complete quality tracking and detection. We have passed the certification of ISO9001: 2000 Quality Management System, and the quality management during production strictly executes 9001 standard. The company has ranked among the industry in China, our users spread all over China and our products are exported to many countries and regions in Southeast Asia, South Africa, America, etc. We have established good cooperative relationship with many manufacturers and distributors, forming wide product marketing channels.
Wuxi Jing Jia International Trade Co., Ltd. will give play to its advantages of technology, market channel and market development capacity to provide professional and excellent service for manufacturers and users at home and abroad.
