Casting & Forging Manufacturers and Factories

Home Casting & Forging Products Products Air Power Drop Forging Hammer with CE Approved

Products Air Power Drop Forging Hammer with CE Approved

Products Air Power Drop Forging Hammer with CE Approved
Price: US $ 1/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: L/C,T/T
Prod Model: C41-25
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Max Hit Force: 0.27kg
Hit Frequency: 250 Times/Min
Speed Of Motor: 1440rmp
Overal Dimension: 980*510*1200/1150mm*510mm*1400mm
Forging Forming Method: Mold Forging

Product Description


C41-25KG Products air power forging hammer with ce  approved

Main Features

The air hammer with small size,low noise,simple structure ,
easy operation ,flexible movement and convenient to transit ,
installation ,maintenance ,the type is widely used for various of free forging works ,
such as drawingout ,upsetting ,punching ,chiseling .forging welding ,bending and twisting .
It is also used for opendie forging in bolster dies.
it is suitable for free forging works of all kinds of different shape parts ,
especially suitable for village township enterprise and selfemployed forge small agriculture tools .
For example sickle ,horseshoes ,Spike ,hoe etc .
At the same time ,the industrial enterprise use the air hammer to forge the steel ball ,
scaffold and many other factories and mines ,construction supplies .
In addition the series air  hammer is very commonly professional blacksmith's iron tools
that can install all kinds of mould to forge a variety iron flowers ,birds and other beautiful decoration.

Specifications
1.Durable and great power
2.Easy installation and operation
3.Convenient maintenance
4.Professional hammer die upon your need
SPECIFICATIONUNITC41-25(Integrated)C41-25 (Separated)
Max. hit forcekj0.27
Height of working areamm240
Hit frequencytimes/min250
Dimension of top & bottom die surface(L*W)mm100*50
Max. square steel can be forgedmm40*40
Max. round steel can be forged(Diameter)mm45
Motor powerkw3/220V 1PH 2.2/380V 3PH3
Speeds of Motorr.p.m1440
Anvil weightkg 250
Total weight(N.W/G.W)kg560/660760/860
Overall dimensions(L*W*H)mm980*510*1200980*510*1200
The main products include machine tools like Plano Miller/Plano Milling Machine/Gantry Milling Machine/Planer Milling machine, Conventional Milling Machine & Milling/Drilling Machine, Vertical Lathe, Horizontal Lathe, Radial Drilling Machine, Vertical Drilling Machine, Gear Shaper & Hydraulic Shaper, Press, Shearing Machine, Press Brake, Saw Machine, Riveting Machine, Air Hammer, etc; Accessories like Vice, Angle Clamp, Slotting Head, DRO, Dividing Head, Rotary Table, Grinding wheel balancer, Universal Boring Head, Clamp kits, etc. And the other product range is garage equipments like Cylinder(Blocks) Boring Machine/Fine Boring Machine, Cylinder Honing Machine, Brake Drum Boring Machine, Brake Lathe/Brake Drum(Disc) Cutting Machine, etc.

All of them have adopted modernized ISO Quality Management System, sound operational procedures as well as effective service system. All the commodities are carefully produced and we bear in mind that products with consistent good quality are crucial to the ongoing success of your operations.
