Prod Model: |
dx75 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Name: |
Omega Profile Roll Forming Machine |
Use: |
Roof and Wall |
Voltage: |
380V 60Hz or at Your Request |
Dimension(L*W*H): |
5000X 800 X 1145mm |
Weight: |
2500kg |
Minimum Order Quantity: |
1 Set |
Color: |
Glue or as Require |
Port: |
Tianjin |
Control System: |
PLC |
Hydraulic Station Power: |
7.5kw |
Forging Forming Method: |
Mold Forging |
Product Description
Omega profile roll forming machine
Technical Datas roll forming machine |
1 | Material width | As your regards |
2 | The effective width | As your regards |
3 | The thickness of Coil | 1.1-2.2mm or more |
4 | Application | wall sheet and roof sheet |
5 | The overall dimensions | 6800mmX1500mmX1300mm |
6 | Total weight | 5 Tons |
7 | Main Power | 5.5 KW |
8 | Uncoiler | Manual Uncoiler |
9 | Inner diameter | 508--610mm |
10 | Outer diameter | 1200mm |
11 | Loading weight | 5 T |
12 | Forming speed | 10-12m/min |
13 | Forming steps | 13 stations |
14 | Bracket | welded with 36 # I-steel |
15 | Material of Shafts | 45# steel with rough finished and then refined finished |
16 | Diameter of the Roll | 76mm |
17 | Material of Rolls | high quality 45#steel coated with hard chromium 0.05mm |
18 | Processing Technology | rough processing ---refined processing--Hard Chromium Plating. |
19 | Material of Rack | complete welded structure of A3 steel plate 16mm thickness |
20 | Transmission | Transmitted by the chain-bracket |
21 | Material of Chain | 45#steel with heat treatment of HRC45-50° |
22 | Holders under chain for lubricant | By the machine |
23 | Material of cutting blade | Cr12 with quenched treatment 60-62 |
24 | Cutting system | Hydraulic cutting |
25 | Voltage | 380V/50HZ/3phase |
Company Introduce:
Our enterprise, Cangzhou Dixin Roll Forming Machine Co., Ltd, as the professional and leading manufacturer, can manufacture, design, installation and debug various roll forming machines and metal processing sheet equipments, which produce metal roof wall panel, glazed roof tile, CZ steel purlin, floor decking, roof ridge cap, sandwich panel, roof truss, shutter panel, shutter slat, door frame, guardrail, and metal sheet uncoiler, bending, slitting, cutting, flattening, punching, crimping.
Backed by reasonable design, precision machining and selected material, both our standard and customized machines are characterized by long life span, precise forming and easy operation. With our customers' trust, our machines have been sent to America, Australia, Russia, India, Sri Lanka, Nigeria, Pakistan, Uzbekistan, Mozambique, Angola, Turkey, Brazil, etc.
Warmly welcome to China to visit our factory and select the machines you need. Our address,Fuzhuang Industrial Development Zone, Botou City, Hebei Province, China
We can design machine according to customer's panel profile.If you have any interest or question,please feel free to contact me
Online contact will get big discount!
Our enterprise, Cangzhou Dixin Roll Forming Machine Co., Ltd, as the professional and leading manufacturer, can manufacture, design, installation and debug various roll forming machines and metal processing sheet equipments, which produce metal roof wall panel, glazed roof tile, CZ steel purlin, floor decking, roof ridge cap, sandwich panel, roof truss, shutter panel, shutter slat, door frame, guardrail, and metal sheet uncoiler, bending, slitting, cutting, flattening, punching, crimping and sandwich panel forming machine.
We exports to most of the world. USA, UK, Africa, Russia, Indian and many other countries.
The davantage of our factoy is that
1. Many panel profile drawing machine designs available
2. Good quality machine
3. Good communication and good after sale service
In the next five years, we provide much better quality machine at reasonable price but competitive than Other supplier. So we can earn more market in the world.
Pls contact for more business.
