Mining Heavy Duty Slurry Pump (3/2 C-AH)

Mining Heavy Duty Slurry Pump (3/2 C-AH)
Price: US $ 3000/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: T/T
Prod Model: AH
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Paiting: Different Colour
Working Pressure: High Pressure Pump
Position Of Pump Shaft: Horizontal Pump
Impeller Number: Single-Stage Pump
Influent Type Of Impeller: Single Suction Pump

Product Description

DESCRIPTION:

Name: NP-AH(R), M, HH Slurry Pumps
Pump Type: Centrifugal Horizontal, single or multistage Slurry Pump
Drive Type: ZVz/CRz/CV/DC
Power: Motor / Diesel
Discharge Size: 1 to 18 inch
Capacity: 0-1000 (l/s)
Head: 0-70(m)

Featurer:

Naipu® NP-AH(R) series centrifugal slurry pumps and spare parts can fully interchange with world famous brand. These pumps are of heavy-duty construction, designed for continuous pumping of highly abrasive and corrosive slurries. They feature a wide choice of replaceable abrasion resistant metal or moulded elastomer casting liners and Impellers, which are all interchangeable within a common casting assembly.

Typical Applications---

Minerals Flotation Processing
Electric Factory Coal Preparation
Coal Washing
Chemical Medium Processing
Effluent Handling
Sand And Gravel Handling



Key words: "heavy duty slurry pumps", "mining slurry pumps", "Ash Pump"
Type Allowable Mating Max. Power(Kw) Clear Water Performance Impeller
Capacity/Q m³/hr Head/m Speed/rpm Max Efficiency/% NPSH/m Nos of Vane Impeller Diameter/mm
1.2X1-NP-AH 15 12.6--28.8 6--68 1200--3800 40 2--4 5 152
2X1.5-NP-AH 15 32.4--72 6--58 1200--3200 45 3.5--8 5 184
3X2-NP-AH 30 39.6--86.4 12--64 1300--2700 55 4--6 5 214
4X3-NP-AH 30 86.4--198 9--52 1000--2200 71 4--6 5 245
6X4-NP-AH 60 162--360 12--56 800--1550 65 5--8 5 365
8X6-NP-AH  300 360--828 10--61 500--1140 72 2--9 5 510
10X8-NP-AH  560 612--1368 11--61 400--850 71 4--10 5 686
12X10-NP-AH 560 936--1980 7--68 300--800 82 6 5 762
14X12-NP-AH 560 1260--2772 13--63 300--600 77 3--10 5 965
16X14-NP-AH 1200 1368--3060 11--63 250--550 79 4--10 5 1067
18X16-NP-AH 1200 2520--5400 13--57 200--400 85 5--10 5  1370

Shijiazhuang Naipu Pump Co., Ltd is a professional manufacturing enterprise of slurry pumps located in high and new technology development zone. The enterprise has one group of high quality technical and management talent working in Design, R & D, Production, Sales and Services. The technical team consists of talents specialized in hydraulic machinery, casting, heat treatment, engineering, material science and machining.

The company manufactures its products using advanced technique based on well built management and sales & service system. Product quality is guaranteed with various test and inspection facilities...

Naipu is specialized in the manufacture and sales of slurry pump and pump parts, especially the design and manufacture of products made with high abrasive, anti corrosive rubber material, including NP-AH(R). NP-M. NP-HH. NP-SP(R). NP-G series slurry pump, NP-ZG. NP-ZJG series slurry pump, NP-WS series dredging pump and NP-PNJ series slurry pump.

The products are widely used in mining, power, metallurgy, coal, dreading, building material and other Industrial lines to pump concentrate, tailings, sludge and other abrasive, high density slurries.

Meeting customers' technical requirements and with a long lifespan, lower cost and high safety, our products are sold well all over of China and far to southeast Asia, Noth America, South America, Russia and etc.

We are confident that we can offer customers satisfying products and services with our continuous efforts in product research and improvement. We look forward to working with customers domestic and abroad to build a promising future.

We can develop and produce a range of pumps according to different media situation to meet different duty requirment.

There are rubber material (R08, R12, R26, R33, R38, R55, S03, S12, S31, S21, S51, S52 U01 and etc), wear resistant metal material( A05, A07, A33, A49, A61 and etc), Corrosion Resistant stainless steel material (201, 304, 316, 316lL and etc ), fully meet customers' request.

We can undertake various OEM orders for pumps as well as spare parts customized according to drawings or samples.
