| Prod Model: | MAN L16/24 |
                        | Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
                        | Material: | Ggz-Cuvti22 |
                        | Cast: | Centrifugal Casting |
                        | Bore Dia.: | 160mm |
                        | Hone Angle: | 50 Degree |
                        | Fuel: | Diesel Engine |



        Product Description
        The
MAN 16/24 Cylinder Liner is supplied to OEM engine maker in China with high quality.
1. Material: GGZ-CuVTi22 alloyed cast iron
2. Casting process: Centrifugal casting
3. Micro structure: Pearlite 95% min;
4. Tensile Strength: 300MPa min on test bar;
5. Hardness: HB230-285;
6. Bore finishing: plateau honed;
7. Hone Angle: 50 degree
8. Concentricity: 0.05mm;
9. Hydrostatic test: 3000PSI;
10. Surface: Parco-Lubrize
