Glazed Steel Step Tile Making Machine (XF26)

Glazed Steel Step Tile Making Machine (XF26)
Price: Negotiableset
Trade Terms: FOB,CIF,EXW
Min Order: 1set
Pay Type: L/C,T/T
Glazed Steel Tile making Machine

Application
This type of glazed tile has advantage inclouding beautiful, classical appearance and grace taste. It can be widely used in village, hotel, exhibition, vocation vallage, family construction and outdoor decorate.

Glazed Steel Tile making Machine

Rolling Material: high grade 45# steel(plated chrome on surface)
Equipment Components: Man-Made Uncoiler-Roll Forming Machine-Computer Control System-Hydraulic Control System-Press Form-Cutting


Glazed Steel Tile making Machine

We have a professional design team
Can also design and manufacture according to customer's requirement.


Competitive Advantage
1. noiseless running
2. good quality
3. high grade steel
4. maintenance-free
5. easy to use

No. main parameter of Glazed Steel Tile making Machine
1 Suitable to process Color steel plate
2 Width of the plate 1000/1200mm
3 Rollers 12rows
4 size 7200*1550*1510mm
5 Main moter power 4kw
6 Hydraulic unit power 4kw
7 Thickness of the plate 0.3-0.6mm
8 Productivit 4m/min
9 Diameter of the roller Φ 70mm
10 Voltage 380V 50Hz 3phases
11 Material of the cutting plate Cr12

Prod Model: XF26
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Color: Blue
Forging Forming Method: Rolling Equipment
Botou Xianfa Roll Forming Machine Factory
It is established in 1996, specializing in colored steel tile forming machinery. With the development of the economy, colored steel tile is widely used in constuction industory. Therefor customers need not only large quantity but also high quality. Our factory produced many now machinery such as CNCauto forming machine. Colored steel tile forming machine, colored steel tile equipment, colored steel tile machinery, Antique glazed tile line, roof load bearing line, compound board line, roll shutter door forming machine and dainpipe on the basis of nomal roll forming machine. At the same time we also produce Anode pole equipment of ESP, fast guardrail equipment and exc. Our products such as C&Ztype purline machine cutting systom, automatic punching have already reached the advanced level of the other suppiers. Our products cover all over the country and also are exported to Russia, Myanmar, Mongolia, Rumania, Iraq, south Korea, Canada, Mozambique Bahrain, Bolivia, Angola, Paraguay, Turkey, Sri Lanka, etc. Beautifu appearence, reasonable construction, pretty design of the tile won good reputation from colored tile products line and oversea customers.
