Corrugated Roll Forming Machine

Corrugated Roll Forming Machine
Price: US $ 58000/Set
Trade Terms: others
Min Order: 1/Set
Pay Type: T/T
Prod Model: HIGHFULL
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Machine Type: Roll Forming Machine
Method: Hydraulic Pressure
Processing: Metal Forming Machine
Forging Forming Method: Mold Forging

Product Description

Corrugated roll forming machine, Glazed tile roll forming machine, steel tile roll forming machine

Our products has feasures of
1. Nice appearence
2. High efficiency
3. Low noize and high quality.
4. Easy control.
technical processing
uncoil--roll forming--punching holes--cutting--out table
uncoiler
Usage:It is used to support the steel coil and uncoil it in a turnable way.
Passive uncoil pulled by roll forming system
Loading capacity5T
Uncoiling width450mm(according to the profile)
Inner diameter:450-550mm
Feeding
Usage:Put the raw material(steel plate) through the beach to manufacture and process,4 down and 3 up , it can guarantee
that the products are neat, parallel and everything is uniformity.
Material of axis45#steel
Number3 up,4 down
Diameter of axis100mm
Forming roundMaterial bearing steel (GR15), quenching 60-62 °C
Detailed description:
1. Uncoil width: 1000 mm, width will be cahnged, it depends on the different profile,
2. Speed: 12m15m/min(not including cutting time)
3. Roller stationabout: 22stations
4. Material of roller adopt fine grade 45#steel, processed by numeral control machine tools and the surface is coated with chrome.
5. Material of shaft adopt  fine grade 45#steel, processed by numeral control machine tools and treated by heat. Diameter of shaft is: 76mm

6. Main power:5.5Kw
7. Hydraulic station: power3Kw
8. Hydraulic station pressure:12 Mpa
9. Electrical systemPLC control, computer and transducer are Panasonic brand, encoder is Omron brand
10. The outline of the machine is about800× 1600× 1200mm
11. Material of knife: Cr12MOV
12 Thickness: 0.3-0.8mm
13. De-coiler, driving system, main machine, hydraulic cutting system, hydraulic system, electrical system, output table, hydraulic station.
Terms:
1. Delivery: According to customers' requirement
2. Package: Export standard package for container
3. Payment: TT (30% by TT in advance, 70% by TT after you inspect machine we need)
4. Delivery date: Within 30 working days after receiving deposit
5. Products Warranty: 12 month, and we will provide the technical support for whole life of the
 equipment.
Qingdao Highfull International Trade Co., Ltd. is located in Weifang, Shandong Province, the World Kite Capital, famous for its predominant geographical location and convenient transportation. JiaoJi railways and JiQing expressways traverse east and west, Relying on the good foundation of culture and machinery, as well as our high product quality, perfect after services, we have won the market and made rapid progress.

Our company is a professional designer and manufacturer of metal sheet cold roll forming machine. We has years of experience to design and manufacture the automatic metal sheet cold roll forming machine. With our strong technical force, in the factory, there are more than 60 sets machines, such as milling machine, planing machine, grinding machine, drilling machine, double housing planer, heat-treated furnace and so on. We have more than 30 high-ranking technicians and engineers. The main products includes, roller press, roll bending forming machine, levelling device, slitting machine, color steel tile forming machine, C/Z profile steel forming machine, U channel profile roll forming machine, steel structure equipment, colored sheet door equipment, color steel section equipment, steel sheet corrugation forming machine, steel tile roll forming machine, security door equipment, security door frame equipment, square and round steel tube equipment, door frame section forming machine, auto car plate equipment, motorized tricycles carriage plate equipment, electrocar carriage plate equipment, container equipment, car sections forming machine, stainless steel door equipment, fire door equipment, light steel keel equipment, garage door equipment, solar energy stand equipment, shelf cold roll forming machine, goods shelf section equipment, cable bridge forming machine, cold bending section steel machine, high-speed guardrail equipment, and all kinds of roll mill, roller etc. Cold bending roll forming machine.

We are a high-tech enterprise of producing the steel plate cold roll forming machine, Meanwhile, we are able to produce and design the cold roll forming machine according to our customers' specific requirements.

Our company pursues progress continuous on the way to technological innovation in recent years. We set up research and development center in Shanghai in 2006. We have developed ultrasonic series, eddy currents etc. Nondestructive testing equipment united with Shanghai Jiaotong University and Shanghai Ligong University etc. Research institutions. We cooperate with friends of home and abroad. Our products have been appraised and trusted by customers from abroad and home by their's novel structure and perfect craftsmanship.

Your Satisfaction is our eternal pursuit, we sincerely cooperate with friends of home and abroad to provide them with perfect equipment, first class service and to make mutual progress and development in cooperation.
