GYT-3000 Electric Melting Furnace |
| GYT-2000 Electric Melting Furnace |
Minimum Capacity (T): 0.85 |
| Minimum Capacity (T): 0.7 |
Melting Furnace Rated Capacity (T):7.5 |
| Melting Furnace Rated Capacity (T):5 |
Rated Voltage (V): 380 |
| Rated Voltage (V): 380 |
Phase Number: 3 |
| Phase Number: 3 |
Frequency of Input Current (HZ): 50 |
| Frequency of Input Current (HZ): 50 |
Melting Rate ( t/h): 3 |
| Melting Rate ( t/h): 2 |
Power Consumption(kw h/t) : 230 |
| Power Consumption(kw h/t) : 240 |
Temperature Holding Power (kw): 160 |
| Temperature Holding Power (kw): 120 |
Rated Power (kw): 720 |
| Rated Power (kw): 480 |
Rating Working Temperature (ºC): 1250 |
| Rating Working Temperature (ºC): 1250 |
Cooling Water Pressure (Mpa): 0.2-0.4 |
| Cooling Water Pressure (Mpa): 0.2-0.4 |
Cooling Water Consumption (t/h): 3.8 (Coil water jacket) |
| Cooling Water Consumption (t/h): 3.8 (Coil water jacket) |
Weight of Molten Hook (kg): 330 |
| Weight of Molten Hook (kg): 230 |
|
|
|
GYT-1500 Electric Melting Furnace |
| GYT-1000 Electric Melting Furnace |
Minimum Capacity (T): 0.55 |
| Minimum Capacity (T): 0.5 |
Melting Furnace Rated Capacity (T):2.2 |
| Melting Furnace Rated Capacity (T):2 |
Rated Voltage (V): 380 |
| Holding Furnace Rated Capacity (T): 4 |
Phase Number: 3 |
| Rated Voltage (V): 380 |
Frequency of Input Current (HZ): 50 |
| Phase Number: 3 |
Melting Rate ( t/h): 1 |
| Frequency of Input Current (HZ): 50 |
Power Consumption(kw h/t) : 260 |
| Melting Rate ( t/h): 0.75 |
Temperature Holding Power (kw): 70 |
| Power Consumption(kw h/t) : 260 |
Rated Power (kw): 240 |
| Temperature Holding Power (kw): 70 |
Rating Working Temperature (ºC): 1250 |
| Rated Power (kw): 180 |
Cooling Water Pressure (Mpa): 0.2-0.4 |
| Rating Working Temperature (ºC): 1250 |
Cooling Water Consumption (t/h): 2.8 (Coil water jacket) |
| Cooling Water Pressure (Mpa): 0.2-0.4 |
Weight of Iron Core (kg): 815 |
| Cooling Water Consumption (t/h): 2.8 (Coil water jacket) |
Weight of Molten Hook (kg): 220 |
| Weight of Iron Core (kg): 815 |
|
| Weight of Molten Hook (kg): 105 |
|
|
|
GYT-500 Electric Melting Furnace |
| GYT-750 Electric Melting Furnace |
Minimum Capacity (T): 0.3 |
| Minimum Capacity (T): 0.5 |
Melting Furnace Rated Capacity (T):1.8 |
| Melting Furnace Rated Capacity (T):2 |
Holding Furnace Rated Capacity (T): 3 |
| Holding Furnace Rated Capacity (T): 4 |
Rated Voltage (V): 380 |
| Rated Voltage (V): 380 |
Phase Number: 3 |
| Phase Number: 3 |
Frequency of Input Current (HZ): 50 |
| Frequency of Input Current (HZ): 50 |
Melting Rate ( t/h): 0.5 |
| Melting Rate ( t/h): 0.75 |
Power Consumption(kw h/t) : 260 |
| Power Consumption(kw h/t) : 260 |
Temperature Holding Power (kw): 55 |
| Temperature Holding Power (kw): 70 |
Rated Power (kw): 120 |
| Rated Power (kw): 180 |
Rating Working Temperature (ºC): 1250 |
| Rating Working Temperature (ºC): 1250 |
Cooling Water Pressure (Mpa): 0.2-0.4 |
| Cooling Water Pressure (Mpa): 0.2-0.4 |
Cooling Water Consumption (t/h): 1.6 (Coil water jacket) |
| Cooling Water Consumption (t/h): 2.8 (Coil water jacket) |
Weight of Iron Core (kg): 550 |
| Weight of Iron Core (kg): 815 |
Weight of Molten Hook (kg): 80 |
| Weight of Molten Hook (kg): 105 |
|
|
|
GYT-300 Electric Melting Furnace |
| GYT-300 Hydraulic Tilting Electric Melting Furnace |
Minimum Capacity (T): 0.2 |
| Minimum Capacity (T): 0.2 |
Melting Furnace Rated Capacity (T):1.2 |
| Melting Furnace Rated Capacity (T):1.2 |
Holding Furnace Rated Capacity (T): 2.8 |
| Holding Furnace Rated Capacity (T): 2.8 |
Rated Voltage (V): 380 |
| Rated Voltage (V): 380 |
Phase Number: 3 |
| Phase Number: 3 |
Frequency of Input Current (HZ): 50 |
| Frequency of Input Current (HZ): 50 |
Melting Rate ( t/h): 0.3 |
| Melting Rate ( t/h): 0.3 |
Power Consumption(kw h/t) : 280 |
| Power Consumption(kw h/t) : 280 |
Temperature Holding Power (kw): 45 |
| Temperature Holding Power (kw): 45 |
Rated Power (kw): 90 |
| Rated Power (kw): 90 |
Rating Working Temperature (ºC): 1250 |
| Rating Working Temperature (ºC): 1250 |
Cooling Water Pressure (Mpa): 0.2-0.4 |
| Cooling Water Pressure (Mpa): 0.2-0.4 |
Cooling Water Consumption (t/h): 1.6 (Coil water jacket) |
| Cooling Water Consumption (t/h): 1.6 (Coil water jacket) |
Weight of Iron Core (kg): 420 |
| Weight of Iron Core (kg): 420 |
Weight of Molten Hook (kg): 60 |
| Weight of Molten Hook (kg): 60 |
|
|
|
GYT-200 Electric Melting Furnace |
|
|
Minimum Capacity (T): 0.15 |
|
|
Melting Furnace Rated Capacity (T):0.8 |
|
|
Holding Furnace Rated Capacity (T): 1.5 |
|
|
Rated Voltage (V): 380 |
|
|
Phase Number: 3 |
|
|
Frequency of Input Current (HZ): 50 |
|
|
Melting Rate ( t/h): 0.2 |
|
|
Power Consumption(kw h/t) : 300 |
|
|
Temperature Holding Power (kw): 30 |
|
|
Rated Power (kw): 60 |
|
|
Rating Working Temperature (ºC): 1250 |
|
|
Cooling Water Pressure (Mpa): 0.2-0.4 |
|
|
Cooling Water Consumption (t/h): 1.6 (Coil water jacket) |
|
|
Weight of Iron Core (kg): 221 |
|
|
Weight of Molten Hook (kg): 45 |
|
|
