Arc Down Type Hydraulic Metal Plate Bending Machine

Arc Down Type Hydraulic Metal Plate Bending Machine
Price: US $ 1000-30000/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: L/C,T/T
Prod Model: W11H
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Place Of Origin: Jiangsu, China (Mainland)
Machine Type: Arc Down Type Hydraulic Metal Plate Bending Machin
Material / Metal Processed: Steel
Power: Hydraulic
Certification: CE
After-Sales Service Provided: Engineers Available to Service Machinery Overseas
Electric Components: Schneider, France
PLC\Touch Screen: Delta
Transducer: Omron
Use: Steel Plate Rolling Machine
Forging Forming Method: Free Forging

Product Description

Arc Down Three Roller Plate Rolling Machine Main description: Arc down three roller plate rolling Machine, three roll for the whole drive roller, power through the planetary gear hydraulic motor to provide torque to rolle plate, the workpiece and the basically roll no mutual sliding; The roller driven by hydraulic cylinders for the arc line down movement. Three rollers used in self- aligning roller bearings. This machine has the advantage of a feeding without the aid of assistive devices that is able to complete both ends of the pre-deformation sheet and rolling barrel, curved work, can also carry out sheet metal shaping and leveling some of the work, and the remaining straight edge small. Features . high-precision end pre-bending . NC control and high production efficiency ; . Products with preeminent precision ; . Safety operation ; . Structure of whole set with simple base and convenience for movement ; . Multiple use with correspondent control ; . Rich in bending shape .
Conditions of Sale
1 Time of delivery 45 working days after received 30% T/T deposit
2 Payment Terms 30%T/T deposit, 70% T/T before shipment
3 Packing Normal packing in complete machine, accessories packing in wooden crate
4 Guarantee 18 Months from the date of the machine start-up, except for the usable materials and excluded our technical visits
5 Sale service Freely offer operation manual and quality certification. Freely offer one set of installation and maintenance tools.







Main technical parameters of this  arch line type plate bending machine with three rolls
Model Roll capacity Diameter of upper roll Diameter of lower roll Main motor
(kw)
End  (mm) Central (mm)
W11H-10x1500 8 10 205 165 5.5
W11H-12x2000 10 12 250 185 11
W11H-16x2500 12 16 300 220 18.5
W11H-20x3000 16 20 375 275 18.5
W11H-25x2500 20 25 380 280 22
W11H-30x2500 25 30 410 310 37
W11H-35x2500 30 35 500 410 45
W11H-40x3500 35 40 550 475 45
W11H-45x2500 40 45 520 455 55
W11H-50x3500 45 50 630 540 55
W11H-55x3000 45 55 620 525 75
W11H-60x4000 50 60 780 680 75
W11H-65x3000 55 65 700 595 75
W11H-70x4000 65 70 820 740 90
W11H-75x3500 65 75 780 680 90
W11H-80x3000 70 80 770 675 90
W11H-90x4000 80 90 910 800 110
W11H-100x3000 85 100 820 740 75x2
W11H-110x3500 95 110 940 820 75x2
W11H-120x3000 100 120 900 795 90x2
W11H-140x3000 120 140 960 830 90x2
Our company supplys different kinds of products. High quality and favaroble price. We're pleased to get your Inquiry and we will come back to as soon as possible. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective.
