Prod Model: |
1DN9 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Type: |
Adapter |
Product Description
Metric male tee hydraulic fitting with carbon steel
Raw material: Carbon steel/stainless steel
Technics: FORGED
Type: ELBOW
Place of origin: Zhejiang, china
Model number: 1DN9
Brand name: Laike
Connection: Male
Shape: Reducing
Head code: Round
Color: White, yellow, zinc
Port: Shanghai/ningbo
Available: 500000pieces/month
Packing: Packed in the carton, ploybag inner the carton, carton to the pallet
| THREAD E |
| TUBE O.D |
|
| DIMENSIONS |
|
|
|
PART NO. | E | F | D1 |
|
| A | B | S1 |
|
1DN9-14-04 | M14X1.5 | Z1/4"X18 | 6 |
|
| 27 | 29 | 14 |
|
1DN9-16-04 | M16X1.5 | Z1/4"X18 | 8 |
|
| 29 | 30 | 17 |
|
1DN9-18-06 | M18X1.5 | Z3/8"X18 | 10 |
|
| 33 | 33 | 19 |
|
1DN9-20-04 | M20X1.5 | Z1/4"X18 | 12 |
|
| 37 | 37 | 22 |
|
1DN9-20-06 | M20X1.5 | Z3/8"X18 | 12 |
|
| 37 | 37 | 22 |
|
1DN9-22-06 | M22X1.5 | Z3/8"X18 | 14 |
|
| 37 | 37 | 22 |
|
1DN9-22-08 | M22X1.5 | Z1/2"X18 | 14 |
|
| 37 | 37 | 22 |
|
1DN9-24-06 | M24X1.5 | Z3/8"X18 | 16 |
|
| 37 | 33 | 24 |
|
1DN9-24-08 | M24X1.5 | Z1/2"X18 | 16 |
|
| 33 | 37 | 24 |
|
1DN9-30-08 | M30X2 | Z1/2"X18 | 20 |
|
| 40 | 40 | 27 |
|
1DN9-30-12 | M30X2 | Z3/4"X14 | 20 |
|
| 40 | 40 | 27 |
|
1DN9-36-16 | M36X2 | Z1"X11.5 | 28 |
|
| 49 | 49 | 33 |
|
1DN9-42-16 | M42X2 | Z1"X11.5 | 30 |
|
| 57 | 57 | 44 |
|
1DN9-42-20 | M42X2 | Z1.1/4"X11.5 | 30 |
|
| 57 | 57 | 44 |
|
1DN9-52-20 | M52X2 | Z1.1/4"X11.5 | 38 |
|
| 56 | 60 | 55 |
|
1DN9-52-24 | M52X2 | Z1.1/2"X11.5 | 38 |
|
| 56 | 60 | 55 |
|
Description Of Products:
1. Raw Material: Carbon Steel & Stainless Steel available
2. Standard Plating: Trivalent Zinc Plating ( Cr3 / Chrome Free ), Silver & Yellow
3. Salt Spray Test: > 72 Hours ( If customer have higher requirement, we can also do with 200 Hours )
4. Packing: Products are protected with the plastic caps and then packed in carbon box.
5. OEM Service: Available. Customer only need to provide the product drawing or samples.
6. Product Dimension: Please kindly contact our sales person for more detailed information.
Our Competitive Advantages:
1. Manufacturer of High quality hydraulic fittings with competitive price.
2. Timely & Prompt delivery
3. Customized Services, more than 40, 000 different items for selection. And large stock prepared.
4. ISO 9001 Certificated
5. First class CNC machines equipped and technical support with over 20 technicians.
6. Considerate after-sale service
