Y81t-4000c Hydraulic Scrap Metal Iron Copper Baler Machine (factory and supplier)

Y81t-4000c Hydraulic Scrap Metal Iron Copper Baler Machine (factory and supplier)
Price: Negotiable/Piece
Trade Terms: FOB,CFR,EXW
Min Order: 1/Piece
Pay Type: L/C,T/T
1. Product Name:
Y81T-4000C Hydraulic scrap metal iron copper baler machine(factory and supplier)

2. Applications:
Y81 series of metal baler are applicable in steel plants, recycling companies, ferrous & non-ferrous smelting industry to press metal scraps(steel, copper, aluminum, stainless steel, discarded automobiles)into acceptable fumace charges(shapes: Cuboid; Cylinder or octagon), so as to reduce cost of transportation, to increase speed of fumace charging.

3. Features
1)Hydraulic drive for all machine types, manual valve control or PLC control.
2)Bale-discharging: Turn-out, push-out, forward-out or manual discharging. Equipped for power.
3)No footing bolts needed in installation; Diesel engine can be equipped or power
4)Baling force 10 grades from 63 to 400 tons; Productivity from 4 to 40 tons per shift(8 hours)

4. Quality standard:
The machines apply to CE/ISO9001: 2000/SGS

5. Service:
Lifelong maintainance and considerate technical support!

Any interest in our products, pls contact me by email or chatting online.

Name: Cathy Hu
Tel: 86 13771607710
Model Nominal Force (KN) Material box size(L*W*H) (mm) Bale Size (mm) Bale Density (kg/m 3 ) Capacity (kg/h) Cycle Time (s) Power (kw) Bale Discharging Operation
Y81-630 630 1000*600*500 (180-250)*200*200 > 1800 500-1000 90 7.5 Over packet,manual
Y81-1000 1000 1000*600*500 (200-300)*230*230 > 1800 1000-1200 120 11 Over packet,manual
Y81/T-1000 1000 1000*600*500 (200-300)*230*230 > 1800 1000-1200 120 15 Push,manual
Y81-1250 1250 1200*700*600 (150-360)*300*300 > 1800 1000-1500 120 15 Push,manual
Y81/T-1250 1250 1200*700*600 (250-400)*300*300 > 1800 1500-2000 80 18.5 Push,PLC
Y81Q-1350 1350 1400*600*600 (240-450)*600*240 > 1800 1800-2500 80 22 Before packet,manual
Y81-1600 1600 1600*1000*700 (400-600)*400*400 > 1800 2000-3000 150 22 Push,manual
Y81/T-1600A 1600 1600*1000*800 (400-600)*400*400 > 1800 2000-3000 150 22 Push,manual
Y81/T-1600B 1600 1600*1200*800 (400-600)*400*400 > 1800 2000-3000 160 30 Push,manual
Y81-2000 2000 1600*1200*800 (400-600)*400*400 > 1800 2500-4000 160 30 Push,manual
Y81/T-2000A 2000 1600*1200*800 (400-650)*400*400 > 1800 2200-4000 160 30
Y81/T-2000B 2000 1800*1400*900 (400-700)*450*450 > 1800 2500-4500 160 37
Y81-2500 2500 2000*1400*900 (400-700)*500*500 > 1800 3500-5000 160 37
Y81/T-2500A 2500 2000*1400*900 (400-700)*500*500 > 1800 3500-5000 160 44 Push,PLC
Y81/T-2500B 2500 2000*1750*1000 (450-800)*500*500 > 1800 3500-5000 160 60
Y81-3150 3150 2000*1400*1000 (400-700)*500*500 > 1800 3500-5000 160 60
Y81/T-3150 3150 2000*1600*1200 (450-700)*550*550 > 1800 4000-5000 160 66 Push,PLC
Y81/T-4000A 4000 2000*1600*1200 (450-800)*550*550 > 1800 5000-6000 160 74 Push,PLC
Y81/T-4000B 4000 2600*2000*1200 (500-1000)*600*600 > 1800 5000-7000 180 90 Push,PLC
Y81/T-4000C 4000 5000*2000*1200 (500-1200)*700*700 > 1500 8000-10000 200 135 Push,PLC
Y81/T-6000 6000 3200*2000*1200 (500-1200)*700*700 > 1800 7000-9000 180

Prod Model: Y 81 T
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Quality Certification: CE;ISO9001:2008;SGS
Type: Packing Machine
Application: Machinery & Hardware
Push Force: 4000/400
Brand Name: Tfkj
Forging Forming Method: Free Forging
Sincere cooperation, Create a win-win situation

Jiangyin Tianfu Technology Co., Ltd. is a domestic R & D production of large and medium-sized scrap processing equipment and hydraulic equipment backbone enterprises, but also the Asia-Pacific region' S largest manufacturer and well-known enterprise of scrap metal hydraulic baler, non-metallic baler, metal shear, scrap car baler, the company has become the key R&D unit in waste recycling machinery industry, has been the permanent member of CAMU and CRRA, got recommendation as scrap processing equipment unit. Products are widely used in materials recycling, waste utilization, scrap automotive and other industries, favored by the users, currently has a scrap metal packaging, shear, scrap cars packed shearing, crushing and fire scrap processing equipment, more than ten series, more than 80 varieties of products. Products are exported to the United States, Japan, Russia, India, Brazil, Africa, Europe, Southeast Asia and other more than 70 countries and regions.

The company now has production capacity of more than 3, 000 sets of large and medium-sized hydraulic machinery as annual output, and a highly qualified, young, innovative and strong research team who founded postdoctoral research workstation with the establishment of Hefei University. According to the users' Customized needs, the company can make special types. In recent years the company developed new products every year more than 10, each with national patent.

With the honor of "Private technology enterprise in Jiangsu Province", also the key unit to be promoted as Quality & prestige double safeguard demonstration unit in China Light Product Quality Assurance Center.

All the products of Tianfu are in strict accordance with ISO9000, ISO2000 and CE certified quality management system standard operation.

Tianfu people are always leaded by spirit "self-imposed pressure, harmony progress, technological innovation, Resplendence Accomplishment". The company' S philosophy is "Serving the customers as the eternal quest, focusing on the market value as the center ". Serving in good faith and making customer satisfying is the objective of all employees in Tianfu.
