1, The frame is the whole welded structure, the whole tempered by the fireplace, the machine to maintain good accuracy.
2, Hydraulic pressure on the acting, stepless voltage regulation, the use of imported high-quality seals to ensure the reliability of the machine.
3, Mechanical synchronization, down complex compensation structure to improve the machining accuracy.
4, The machine has jog, single, continuous practices, commutation, dwell time can be controlled by time relay.
5, The machine equipped with a safety fence and door power equipment, improved safety in operation.
6, Cylinder with synchronous control servo valve, hydraulic concave automatic compensation system organizations can control the back gauge mutipe-axis back gauge, welded steel plate body, the whole by tempering.
|
Specification |
Nominal pressure
(KN) |
Length of working table
(mm) |
The distance between column
(mm) |
Open heigh
(mm) |
The depth of throat
(mm)
|
Ram Stroat
(mm)
|
Motor power
(KW) |
Overall Dimensions
(mm) |
|
WC67K-200T/6000 |
2000 |
6000 |
4800 |
435 |
320 |
200 |
15 |
6100× 1750× 3360 |
Nantong Weili Equipment Machine Co., Ltd., is a specialized manufacturer of guillotine shear and press brake diretly under the State Minstry of Machinerty Industry. The products "TONGWEI" brand are sold to all over the country and sold to Europe, America, MID-east, South Afica, Southeast Asia, etc, more than 30 countries.
Our products are widely used in machinery, plane, car, ship, vessel, packing, stainless steel, decoration and so on. Customers from home and abroad are warmy welcome to our company.
