Product Name: Stainless Steel Casting
Material:
No ASTM GB
1 CA---15(410) ZG1Cr13
2 CA---40(420) ZG2Cr13
3 ---- ZGCr28
4 CF---3(304L) ZG00Cr18Ni10
5 CF---8(304) ZG0Cr18Ni9
6 CF---20(303) ZG1Cr8Ni9
7 CF---8C(347) ZG0Cr18Ni9Ti
8 CF---3M(316L) ------
9 CA---8M(316) ZG0Cr18Ni12Mo2Ti
10 ---- ZG1Cr18Ni12MoTi
11 CH---10(309S) ZG0Cr25Ni12
12 CH---20(309) ZG1Cr25Ni12
13 CK-20(310) ZG1Cr25Ni20
Casting Tolerance & Linear Tolerance
Dimensions(mm) Normal(mm) Premium(mm)
3----10 0.36 0.26
11-----25 0.42 0.30
26-----63 0.50 0.36
64-----100 0.56 0.40
101-----160 0.62 0.44
161------250 0.70 0.50
251-----400 0.78 0.56
Ningbo Ruyi Foundry Co., Ltd. is your reliable source for Ductile iron casting, Grey iron casting and you can also entrust us for Stainless steel casting, Aluminium alloy casting and Refractory steel casting. The moulding process covers Resin Chemically Bonded Sand Cast, Resin Shell Cast, and Green Sand Cast. Based on the land of size 6000 square meters, the foundry's monthly iron casting output capacity is up to 350 tons, and 80% of the produced castings are sold to overseas markets. Our castings mainly apply to Machine tools industries, Pumps industries, Gas & steam valve industries, Automobile industries, Air compressor industries, Gear cases & accessories, Electric motor body & accessories, Other products.
The foundry conforms to international standards and offers material analysis, heat treatment, non-destructive testing, proof and precision machining. With great efforts and carrying out our policy continuously which is to produce castings to meet your individual requirements, as well as monitoring each stage of production to guarantee high quality, we finally got certified by ISO9001: 2000.
