Spiral duct machine modle MHTF-1500 with saw blade cutting and with band steel mould which is more convinent and economic.
Diameter range |
Φ80-Φ1500mm |
Tube Length |
100-8000mm |
Thickness of Strip |
0.4-1.2mm |
Width of Strip |
137-140mm |
Strip Speed |
1-38/min |
Dimension (L x W x H): |
2650*1550*2000mm |
Weight |
2200kg |
Control System |
PLC automatic control |
Compressed air power |
0.5-0.7kmp |
Connected load |
380V/3P/50HZ |
Main Motor Power |
5.5kw |
The power of hydraulic pressure motor |
4kw |
Suitable Material |
Aluminum, Stainless steel, Galvanized steel |
Our company is to supply steel processing equipment, such as tube mill, cut to length, slitter, cold rolling mill, duct production machines, press braker, shear, and other steel equipment. Our machine has high quality and competitive price.
With our technical innovation, our machine can reduce power consumption, increase efficiency.
We export machines to South East Asia, India, USA, Middle East area, Europe, Africa, etc. Our goal is to meet customer requirement, increase customer production rate and accuracy, and give customer more value. Business will make both customer and us win.
