Our Fanshun hardware machine factory supply one-stop integrated solutions for brass rod, brass pip, brass components, tap, valves, lock and key and so on.
Introduction and structure
Melting furnace and holding furnace are tied together. No smoke furnace itself while melting. Auto constant temp control unit is available. Widely used in the field of brass, copper alloy products.
Both furnace connect through bottom, raw material melted down, liquid can be flowed to holding
Furnace chamber after component of liquid met special requirement. We this design structure can
Reduce smoke, loss of zinc because of oxidizing. Energy consumption is less.
The main frequency cored induction furnace is composed by furnace body, inductor, cabinet, the
Inductor is installed under furnace body, include iron core, copper loop, coil, water jacket and so on.
Solutions for 4.5 ton/day production line
1 120kw melting furnace
Specification:
Model: GYT-500
Power: 120(kw)
Melting rate: 500kg/h
Capacity: 4.5 ton
Quantity: 1 unit
2 Die casting machine
Specification:
Model: SYO-75
Speed: 0-0.035m/s
Casting diameter: 6-75mm
Quantity: 2 set
3 Pneumatic sawing machine
Specification:
Model: Q75
Cutting size: Φ 6-75mm
Speed: 10s/PCS
Power: 3kw
Air pressure: 0-1 Mpa
Quantity: 2 set
4 Heading machine
Specification:
Model: CZ-C
Heading size: Φ 6-75mm
Heading length: 50-120mm
Cutter: 4 set
Motor power: 4kw
Quantity: 1 set
5 Peeling machine
Specification:
Model: 5T
Peeling size: Φ 10-75mm
Working length: 3m
Speed: 15-25m/min
Power: 18.5kw
Quantity: 1 set
6 Hexagon, Square straightening machine (horizontal and vertical)
Specification:
Model: YT-22C
Straightening size: S10-50mm
Precision: 0.2mm/100mm
Motor power: 5.5+5.5 kw
Quantity: 1 set
7 Two roller straightening machine
Specification:
Model: TP2C
Straightening size: Φ 15-70mm
Precision: 0.2mm/100mm
Motor power: 11kw
Quantity: 1 set
8 Two roller straightening machine
Specification:
Model: TP2B
Straightening size: Φ 6-16mm
Precision: 0.1mm/100mm
Motor power: 7.5kw
Quantity: 1 set
Pls feel free to contact us directly through below detail:
Miss Sofia
Cellphone: +86-13923243770
Sofia(+0086-13923243770)
Our company, founded in 1994, is located in Foshan City, Guangdong Province, in the Pearl River Delta of Nanhai. Our factory covers a building area of 4000 square meters, with all kinds of mechanical processing equipment. Engaged in research and development, we are a professional manufacturer of many kinds of copper rod, brass and lead casting machines, straightening machines, straightening and polishing machines, hydromatic drawlooms, copper and aluminum melting furnaces, temperature holding furnaces and other production equipment. Our company regards environmental protection, energy conservation, and non-pollution as the important index of electric furnace production equipment. We provide price inquiries, technical consultation, training, maintenance and reasonable equipment matching guidance for a new copper factory.
After several years' effort, our factory has developed the following new equipment: Conveyor belt multiple absorbing iron machines, vibration absorbing iron machines, high efficiency low loss combo furnaces, vertical type double acting lead casting machines, automatic peeling machines (no need for heading), automatic combined drawing machines, copper ash cleaning re-blowing production lines, aluminum casting machines, and vacuum casting heading machines for profiled rods (one-time heading).
Our factory always adheres to the principle of "improvement, inspiring innovation, quality first, customer first", and is dedicated to the general customer service with high quality services and low prices. We welcome clients from at home and abroad to come to negotiate business with us. We are willing to work with you.
