Single Cylinder Punching Machine (Q55Y-140)
| Price: |
Negotiable/Piece |
| Trade Terms: |
FOB,CIF |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T |
Features:
The EMM model of hydraulic punching machines all come equipped with a deep throat of 600mm as standard. Heavy-duty support tables with scales and backstops, universal die holder for punching in plate, flat bar, angle iron and flange of channel and beam are all part of the standard execution. The EMM hydraulic punching machines are available from 60 ton to 200 ton. Furthermore, tooling from competitor's machines and or other brand-names can be used without special machine-modifications. The standard machine comes equipped with a deep throat and universal die-bolster, punching up to 57mm diameter/slot. The front part of the table can be removed in order to punch in large format angle-iron.
|
Model |
Unit |
Q55Y-140 |
|
Punching Pressure Ton |
Ton |
140 Ton |
|
Max. capacity |
mm |
35x28 |
|
Diameter x thickness |
mm |
57x16 |
|
Stroke length |
mm |
80 |
|
Standard throat depth punch |
mm |
600x600 |
|
Largest hole(standard equipment) |
mm |
57 |
|
Largest hole(optional equipment) |
mm |
160 |
|
Maximum section |
mm |
380 |
|
Working height |
mm |
1075 |
|
Corner notch(optional equipment) |
mm |
- |
|
Maximum capacity |
mm |
250sq x 6 |
|
Tube notch(optional equipment) |
mm |
- |
|
Maximum outside diameter |
mm |
165 |
|
Bending(optional equipment) |
|
- |
|
Bar bend. max. capacity |
mm |
250x22 |
|
Sheet bend. max. capacity |
mm |
600x3 |
|
Technical data |
|
- |
|
Motor power |
kw |
13 |
|
Net weight-punch |
|
3800 |
|
Machine dim. (Lx W x H) |
mm |
2700x1120x2160 |
| Prod Model: |
Q55Y-140 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
