This machine is used for scrolled strip shearing for round can bottom, it can also be used for double knife scrolled strip shearing for big can end. It can save 7~9% material compared to other shearing machine. It is equipped with double sheet detector, sheet de-shape overload and knife safety etc protection units. It has PLC controller.
Model
Technical data |
GT1B9
Scroll shearing machine |
|
Max tin sheet size |
1170*1170 mm |
|
Max tin sheet size |
750*508 mm |
|
Max cutting thickness |
0.4 mm |
|
Max material feeding stroke |
350 mm |
|
Max double mold cutting width |
260 mm |
Cutter reciprocate time |
big cover
50-100 times/min |
small cover
50-100 times/min |
|
Power |
5.75kw |
|
Weight |
8000kg |
|
Outer dimension |
4520*2505*1615mm |
