Shear Size (T×W)(mm) |
Shear Angle | Strokes(min -1 ) | Backgauge Range (mm) | Main Motoer(kw) | Weight (kg) | Overall Dimensions (L×W×H)(mm) | |
| QC12Y-4×2500 | 4×2500 | 1°30' | ≥18 | 20-600 | 7.5 | 4,800 | 3040×1610×1650 |
| QC12Y-4×3200 | 4×3200 | 1°30' | ≥14 | 20-600 | 7.5 | 6,400 | 3840×1610×1650 |
| QC12Y-4×4000 | 4×4000 | 1°30' | ≥10 | 20-600 | 7.5 | 7,900 | 4640×1705×1700 |
| QC12Y-4×5000 | 4×5000 | 1°30' | ≥10 | 20-600 | 7.5 | 16,000 | 5786×2200×2160 |
| QC12Y-6×2500 | 6×2500 | 1°30' | ≥18 | 20-600 | 7.5 | 5,500 | 3040×1610×1650 |
| QC12Y-6×3200 | 6×3200 | 1°30' | ≥14 | 20-600 | 7.5 | 6,600 | 3840×16100×1650 |
| QC12Y-6×4000 | 6×4000 | 1°30' | ≥10 | 20-600 | 11 | 8,500 | 4640×1705×1700 |
| QC12Y-6×5000 | 6×5000 | 1°30' | ≥10 | 20-750 | 11 | 16,000 | 5786×2200×2060 |
| QC12Y-6×6000 | 6×6000 | 1°30' | ≥10 | 20-800 | 11 | 17,500 | 6730×2500×2090 |
| QC12Y-8×2500 | 8×2500 | 1°30' | ≥14 | 20-600 | 11 | 6,000 | 3040×1610×1650 |
| QC12Y-8×3200 | 8×3200 | 1°30' | ≥10 | 20-600 | 11 | 7,000 | 3840×1610×1650 |
| QC12Y-8×4000 | 8×4000 | 1°30' | ≥8 | 20-600 | 11 | 9,200 | 4680×1705×1700 |
| QC12Y-8×5000 | 8×5000 | 1°30' | ≥7 | 20-600 | 15 | 21,000 | 5786×2252×2310 |
| QC12Y-8×6000 | 8×6000 | 1°30' | ≥5 | 20-750 | 15 | 28,000 | 6900×2570×2280 |
| QC12Y-10×2500 | 10×2500 | 2° | ≥11 | 20-750 | 15 | 8,500 | 3350×2050×1950 |
| QC12Y-10×3200 | 10×3200 | 1°48' | ≥10 | 20-600 | 15 | 9,500 | 4050×2050×1950 |
| QC12Y-10×4000 | 10×4000 | 2° | ≥12 | 20-600 | 18.5 | 14,500 | 4800×2200×2100 |
| QC12Y-12×2500 | 12×2500 | 1°40' | ≥11 | 20-800 | 15 | 8,500 | 3350×2050×1950 |
| QC12Y-12×3200 | 12×3200 | 1°40' | ≥10 | 20-600 | 18.5 | 12,500 | 4020×2050×2230 |
| QC12Y-12×4000 | 12×4000 | 1°40' | ≥8 | 20-800 | 18.5 | 18,000 | 4820×2400×2300 |
| QC12Y-16×2500 | 16×2500 | 2°20' | ≥8 | 20-800 | 18.5 | 11,500 | 3445×2477×1880 |
| QC12Y-16×3200 | 16×3200 | 2°20' | ≥7 | 20-800 | 18.5 | 13,800 | 3945×2477×2035 |
| QC12Y-16×4000 | 16×4000 | 2°20' | ≥5 | 20-800 | 18.5 | 15,300 | 4745×2477×2035 |
| QC12Y-20×2500 | 20×2500 | 2°30' | ≥6 | 20-800 | 30 | 16,000 | 3440×2088×2570 |
| QC12Y-20×3200 | 20×3200 | 2°30' | ≥5 | 30-800 | 30 | 18,000 | 4150×2350×2710 |
| QC12Y-20×4000 | 20×4000 | 2°30' | ≥5 | 30-1000 | 37 | 21,000 | 4920×2400×2730 |
| QC12Y-20×5000 | 20×5000 | 2°30' | ≥4 | 20-800 | 37 | 30,000 | 5900×3000×3300 |
| QC12Y-25×2500 | 25×2500 | 3° | ≥5 | 40-800 | 37 | 21,000 | 3500×2400×2500 |
| QC12Y-25×3200 | 25×3200 | 3° | ≥4 | 40-1000 | 37 | 26,000 | 4200×2400×2500 |
