Characteristics:
1. ) Body Material: The body made of high grade and high strength cast iron, via stress-relief annealing and natural ageing treatment to ensure the coefficient of deformation is minimum and the steady precision.
2. ) Lubrication system: Adopts complete-closed lubrication system and the special industrial design, so that, the cooling of main body can be faster and more natural.
3. ) The high precision processing equipment, strict processing guarantee, and many kinds of filtration system (include magnetic filter head) to ensure that the coefficient of kinetic friction <0.03.
4. ) Oil hydraulic locking system: With 250 kg f / cm ², high-pressure automatic locking system to facilitate the operation and ensure the locking force, solid & precise.
5. ) Equipped with standard reverse dynamic balanced device to realize high speed operation and prolong the useful life of main parts.
6. ) Microcomputer control system: Directly display working status and fault conditions, and with top dead center stop control. It's convenient for mold base and system self-test, and to solve the problems easily.
7. ) Air pressure system: Adopts standard SMC parts to ensure the stability of the system.
8. ) Mould adjustment control system: Adopts the separate structure and self-locking function to enhance the operational safety and the reliability & precision of adjustment.
9. ) Main system of Machine (e. G.: Air, lubrication and air pressure locking): Using pressure display and pressure switch protector device to enhance the stability of the system.
10. ) Guiding device: Adopts three cylindrical location guiding to make sure of the steady precision, and it's easy to test and maintain.
|
Machine Type |
KRD-3T |
KRD-5T |
KRD-10T |
|
Max. Capacity |
Ton |
3 |
5 |
10 |
|
Slide Stroke |
mm |
10~25 ( mm ) |
10~25 |
10~30 |
|
Strokes Per Minute (S.P.M) |
SPM |
200~1200 |
200~1200 |
200~1200 |
|
Die Height |
mm |
170 |
170 |
200 |
|
Slide Adjustment |
mm |
30 |
30 |
30 |
|
Main Electric Motor |
HPXP |
1X4 |
1X4 |
2X4 |
|
Gross Weight |
kg |
1100 |
1200 |
1500 |
|
Air Drang |
kg/cm2 |
5 |
5 |
5 |
|
Machine Type |
KRD-25T |
KRD-45T |
KRD-65T |
|
Max. Capacity |
Ton |
25 |
45 |
65 |
|
Slide Stroke |
mm |
20~30 |
20~30 |
20~30 |
|
Strokes Per Minute (S.P.M) |
SPM |
200~1000 200~800 |
200~1000 200~800 |
200~600 100~500 |
|
Die Height |
mm |
210 215 |
240 235 |
305 300 |
|
Slide Adjustment |
mm |
30 |
30 |
45 |
|
Main Electric Motor |
HP |
5 |
7.5/10 |
10 |
|
Gross Weight |
kg |
4000 |
6000 |
9000 |
|
Air Drang |
kg/cm2 |
5 |
5 |
5 |
KERuiDA is a German-funded corporation, one of the well-known brands in the world. It is specialized in punch machine and mould & die making.
Punch machine making:
In 2005, Keruide Machinery Equipment Co., Ltd. was set up in Dongguan. Introduce Germany advanced technology and professional R&D, to design and make KERuiDA big three round high-speed precision automatism punch and a range of automatic machinery and equipment. We followed the policy of "People-oriented, Morality for the first". With professional technical R&D team, to research a new type of superhigh speed punch according to the customers' special needs. We always continue to improve our products, and due to our high quality and good services, we received the vigorous support and high trust from our customers. Thus, it created "Dongguan Keruide Machinery Equipment Co., Ltd. " a good image in business. And we take "creating the first brand of nation" as a goal.
Mould and die making:
We can provide one-stop service including design and fabrication of tooling, molding products and secondary process such as Silk Screen Printing, Spray Printing and Pad Printing etc. Due to the rich experience, competitive price, on-time delivery and high quality, our moulds and products have been sold very well all over the world, especially in European countries and U. S. In order to adapt to the pace of market development, we earned ISO 9001-2000 certification in 2005, which embodies our efforts in quality management. Advanced equipment, excellent employees, sophisticated techniques, superior quality management, responsive service system, all of these will contribute to our competition. Therefore, we have always kept long-lasting trustworthiness and harmonious Win-win relationship with our customers.
We always keep in mind: To survive on quality, to profit from management, always keep improving. And our slogan is "Take customer's interests firstly, Think what you think, Worry what you worry. "
Therefore, "Choose us, you choose the success! "
