Advantage:
1. Consists of molten-holding furnace, dragger,
2. Crystallizers, speed adjusting gear,
3. Controlled by PLC system
Main data shows below:
Up-casting machine
1. Related furnace 2 units (one furnace for melting, the other one takes charge of holding temp)
2. Winding machine: 3 sets
3. Casting strand: 6 sets
4. Dia of rod: 8mm
5. Casting speed: 0-2800mm/min (servo system controlled by PC)
6. Coil size: 700mm*1500mm
7. Working time: 7900h/year
8. Related transformer: 200KVA
Pulling machine (cast 8mm to 3mm brass bar)
1. Main motor: 75kw
2. Mould Number: 8sets
3. Gear box model: 850
4. Output: 1ton/h
5. Power of winding machine (3mm): 5.5kw
6. Plate of winding machine(3mm) diameter: 500mm-650mm
Wanna to know more information please feel free to contact us! We always there for you!
Our company, founded in 1994, is located in Foshan City, Guangdong Province, in the Pearl River Delta of Nanhai. Our factory covers a building area of 4000 square meters, with all kinds of mechanical processing equipment. Engaged in research and development, we are a professional manufacturer of many kinds of copper rod, brass and lead casting machines, straightening machines, straightening and polishing machines, hydromatic drawlooms, copper and aluminum melting furnaces, temperature holding furnaces and other production equipment. Our company regards environmental protection, energy conservation, and non-pollution as the important index of electric furnace production equipment. We provide price inquiries, technical consultation, training, maintenance and reasonable equipment matching guidance for a new copper factory.
After several years' effort, our factory has developed the following new equipment: Conveyor belt multiple absorbing iron machines, vibration absorbing iron machines, high efficiency low loss combo furnaces, vertical type double acting lead casting machines, automatic peeling machines (no need for heading), automatic combined drawing machines, copper ash cleaning re-blowing production lines, aluminum casting machines, and vacuum casting heading machines for profiled rods (one-time heading).
Our factory always adheres to the principle of "improvement, inspiring innovation, quality first, customer first", and is dedicated to the general customer service with high quality services and low prices. We welcome clients from at home and abroad to come to negotiate business with us. We are willing to work with you.
