| Prod Model: |
QH11D-3.2x1500 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Forging Forming Method: |
Free Forging |
Product Description
QH11D-3.2x1500 Precision Mechanical Shear, Cutting machine, Shearing Machine, Mechanical Shearing machine, Precision Shear, plate shear machine, shearer
QH11D-3.2x1500 Precision Mechanical Shear, Cutting machine, Shearing Machine, Mechanical Shearing machine, Precision Shear, plate shear machine, shearer
Specifications
1. True-cut precision
2. ISO & CQC & export quality lincese
3. Low cutting angle and inclined shearing direction
Character:
This ture-cut Mechanical Shearing Machine introduce the domestic and foreign advanced technology, using motor disc brake, the traditional way of shaft movement with reducer by motor. This type can instantaneous stop with pedal, can have small shearing Angle and tilt of the shear direction, make bending deformation reduced to the minimum. The blade gap adjustment using manual, quick adjustment device, easily can get satisfactory blade gap easily. It is the ideal processing cutting equipment for metal sheet metal or nonmatel sheet.
Feature:
1. Fabricated steel structure, with compact, construction, light weight and good rigidity stability
2. Integrated hydraulic transmission system, with good reliability
3. Back gauge use intelligent digital display device, shear quantity can be automatic counted, distance of back gauge can be set according to requirements of customers
4. The moving orbit of the blade beams inclines forwards to the supporting surface of the bottom blade, so you can gain fine shear surface. Jacking screws of the top blade provide a fine adjustment to minimize "rag" or "burring" on the sheared edge of the material
The hold-down assembly adopts the butterfly springs. There are antiskid heel block on the hold-down device of hold-down plate. The pressure is bigger, but it doesn't damage the sheet-metal surface.
5. The machine is drived by a self-contained, totally enclosed gearbox mounted directly on the main shaft. Its construction is compact and the gear is well lubricated with low noise and long life.
6. The machine hasn't the clutch and the flywheel. It shears the sheet-metal directly drived by the magnetic brake motor. This reduces the idle time of the motor and saves the energy.
7. The front and back gauges are provided with the scale plate displaying the scale. The back gauge may be easily adjusted in synchronism.
WE CAN SUPPLY VARIOUS SPECIFICATION OF MECHANICAL SHEARING MACHINE ACCORDING TO CUSTOMER'S REQUIREMENT, include general mechnical shearing machine
WE ALSO PROFESSIONAL MANUFACTURE HYDRAULIC SHEARING MACHINE (QC11Y/QC11K/QC12Y/QC12K)WITH OR WITHOUT CNC
|
Model |
QH11D-
3.5×1250 |
QH11D-
3.2×1500 |
QH11D-
3.2×2000 |
QH11D-
2.5×2500 |
QH11D-
3.2×2500 |
QH11D-
3.2×3050 |
|
Shearing Thickness (mm) |
3.5 |
3.2 |
3.2 |
2.5 |
3.2 |
3.2 |
|
Shearing Width (mm) |
1250 |
1500 |
2000 |
2500 |
2500 |
3050 |
|
Shear Angle |
1°30′ |
1°30′ |
1°45′ |
1° |
1°18′ |
1°30′ |
|
Number of Stroke (min -1 ) |
47 |
47 |
47 |
47 |
47 |
47 |
|
Back gauge (mm) |
0-650 |
0-650 |
0-650 |
0-650 |
0-650 |
0-650 |
|
Height of Worktable (mm) |
800 |
800 |
800 |
800 |
800 |
800 |
|
Motor Power (kW) |
5.5 |
5.5 |
7.5 |
7.5 |
7.5 |
9 |
|
Net Weight (kg) |
1450 |
1650 |
1800 |
2080 |
2200 |
3600 |
Dimension
(L×W×H) (mm) |
1860×2210
×1180 |
2124×2210
×1180 |
2624×2210
×1180 |
3124×2210
×1180 |
3124×2210
×1180 |
3600×2448
×1290 |
