Precision Lost Wax Carbon Steel Casting Part
Advantages:
1. More than 15 years experience, steady in quality
2. Advance import machine, higher precision
3. Kinds of casting parts available for customers, best choice
4. ISO2001: 2008 verified company, quality control
Specifications:
Material: Stainless steel, cast iron, pig iron, carbon steel, alloy steel, non-ferrous, grey iron, ductile cast iron, etc
Type: Lost wax casting, soluble glass casting, ductile iron casting, sand casting, die-casting, cnc machining, ect
Surface: Polishing, machining, plating, Heat Treatment, painting, ect.
Finish: Zinc plated, Chromated plated, Electrophoresis, Powder coating, Anti-corrosionetc
Standard: OEM manufacturing as per customers requirements or drawings.
Application: Industrial parts, Machinery parts, construction parts, valve parts, train, craft, door handle, hinge, hydraulic pressure, construction, agricultural machinery, auto parts, ect.
Quality Control Process
Raw Material Inspection => Production process => 100% Testing/Inspection by QC => Packaging => Final Random inpsection by QA
Qingdao Chifine Machinery Co., Ltd is one famous company in China which specialized in various metal casting products with over 10 years experience located in Qingdao China. It covers a comprehensive range of forging, stamping, sand casting, investment casting, die casting and machining and was widely used in Agriculture machinery, Motor Vehicle, Architecture, Railway and Engineering
As a professional company, Chifine have four groups of experienced teams to be in charge of different work:
Project team-customer service
Engineering team-provide R&D and technical support
QC team-productive process control and incoming parts inspection
Warehouse team-warehouse management and logistic service
PROCESS
|
MATERIAL
|
STANDARD
|
SAND CASTING
|
Green Sand
|
Grey Iron, Ductile Iron, Malleable Iron, Stainless Steel, Carbon Steel, Aluminium, Brass, Bronze
|
AISI
ASTM
DIN
GB
BS
JIS
NF
AAR
|
Furan Resin Sand
|
Cold Harden Resin Sand
|
INVESTMENT CASTING
|
Sodium Silicone
(Water Glass)
|
Stainless Steel, Carbon Steel, Special Alloy Steel, Bronze, Brass, Aluminium
|
Silica Sol
|
FORGING
|
Hammer Forging
|
Stainless Steel, Carbon Steel, Alloy Steel, Brass, Aluminium
|
Die Forging
|
Roll Forging
|
STAMPING MACHINING
|
|
All Metal Material
|
Qingdao Chifine Machinery Co., Ltd is One Famous Company in China Which Specialized in Various Metal Casting Products with Over 10 Years Experience Located in Qingdao China. It Covers a Comprehensive Range of Forging, Stamping, Sand Casting, Investment Casting, Die Casting and Machining and Was Widely Used in Agriculture Machinery, Motor Vehicle, Architecture, Railway and Engineering Chifine Has Accumulated Important and Valuable Experience in Design, Manufacturing and Customer Service Over These Years We Will Continue to Integrate Our Technical Superiority, Improve Process and Quality to Increase Market Share and Create More Brilliant Future.
Automative Casting Line:
• Material: Grey iron(GG20-GG35); Ductile iron(GGG40-GGG60);
Malleable cast-iron(GTS35-10/45-06/55-04/65-02, CTW35-04/05/06/07).
• Product Size: 0-1000mm.
• Weight: 0.2kg-100kg
Resin Sand Casting
• Material: Grey iron(GG20-GG35); Ductile iron(GGG40-GGG60);
Malleable cast-iron(GTS35-10/45-06/55-04/65-02, CTW35-04/05/06/07).
Steel casting(ASTM/UNS; DIN; JIS; NF; BS; ISO)
• Product Size: 0-1500mm.
• Weight: 10kg-5000kg
Shell Mould Casting
Shell casting is one of resin sand casting process.
It is suitable for thin-wall casting parts, be free from porosity.
• Material: Grey iron(GG20-GG35); Ductile iron(GGG40-GGG60);
Malleable cast-iron(GTS35-10/45-06/55-04/65-02, CTW35-04/05/06/07).
Steel alloy; Aluminum alloy; Copper alloy.
• Product Size: 0-500mm.
• Weight: 50g-100kg.
• Wall thickness: 4-20mm
Lost Wax Casting
• Advanced wax-injection-machine and tool to ensure accurate wax-patten.
• Stable temperature and humidity environment make the wax-patten no deformation.
• Material:
Carbon steel; Stainless steel; Alloy steel.
Grey iron(GG20-GG35).
Ductile iron(GGG40-GGG60);
Malleable cast-iron
(GTS35-10/45-06/55-04/65-02, CTW35-04/05/06/07).
Aluminum alloy; Copper alloy.
• Casting size: 0-500mm.
• Casting weight: 50g-100kg
Stamping and Forging Line
• Stamping and forging equipment: 16T-300T press machine
• Automatic transport forging line
• Material: Carbon steel; Stainless steel; Alloy steel.
Aluminum alloy; Copper alloy.
Machining Shop
Our machining shop located in Qingdao, using the latest CNC equipment to provide our customer with high quality products.
• Horizontal and Vertical Machining Center
• CNC lathe and normal lathe
• CNC drilling and milling Center
• Other assistant equipment
