Forming machine, purlin forming machine, c&z forming machine can form the hot/cold materl strip and can get various specification purlins by changing the spacers.
Technical parameter:
1. Model: C Z
2. Profile: C purline Z purline
3. Purline specification: 100- 250 mm
4. Material:
A)Type: Steel strip
B)Thickness: 2.0-3.0 mm
C)Yield strength: 230-300Mpa
5. Max. Forming speed: 10-13m/min
6. Roller materail: Bearing steel
7. Roller driven type: Chain transmission
8. Controller: PLC
9. Operation: Touch screen+button
10. Hydraulic system pressure: 20 Mpa
11. Hydraulic station motor power: 5.5 KW
12. Main motor power: 15 KW
13. Total power: 20.5 KW
14. Total weight: About 13000 Kg
For over 15 years Baosheng has been designing, building and installing sandwich panel and rollforming lines for metal building products, material handling products, automotive products and many other custom products literally around the world.
We manufacture roll forming machines that are used for making sections such as Z purlin, C channels, roof panels, crash guards, fenders and any section as per customers specific requirement. Our roll tools are designed by experts and meticulously manufactured which ascertains precise forming of section. We make Cold Roll Forming Lines of input strip width varying from 700mm to 1250mm and thickness ranging from 0.3mm to 3mm. The raw materials that the machine can work with are mild steel, galvanized steel, color coated sheets, aluminum to name a few.
Looking forward to hearring from you!
Our Mission is "Quality Up and Price Down".
