Features:
1. Latest technology--IGBT inversion technology reduce operating cost
2. LC series circuit and voltage feedback design achieve energy saving up to 30% compared with SCR technology induction machine
3. Diode rectification technology make sure high power factor - 0.98
4. Soft switch technology and power & frequency tracking automatically improve reliability of equipment
5. Be started up 100% at any load, 100% continue duty
6. Prefect protection system enhance long-term performance
7. Suitable for large size heating part
Application:
Forging & forming
Heat treatment such as hardening, , tempering, annealing and etc.
Melting for aluminum, copper etc
Pipe Pre-heating before welding
Pipe Bending
Optional:
Temperature control system enhance heating precise
External cooling system--DI Water cooling system or chiller, enhance good reliability of induction machine
|
Power Output |
600KW |
|
Oscillating Frequency |
0.5KHz--8KHz |
|
Input Power capacity |
750KVA |
|
Input Voltage |
380V/50Hz |
|
Operation Voltage |
340V-430V |
|
Input Current |
1000A |
|
Continue Duty |
100% |
|
Cooling Water Flow |
25--35m3/h |
|
Weight |
600kg |
|
Dimension |
1500X800X2000 |
Chengdu Duolin Electric Co., Ltd, is the first company in China to professional design and manufacture medium, high and ultrasonic frequency induction heating machine. Now our company is expanded to over 10, 000m2 modern production and two plants, more than 200 employees, forty branch offices all over China.
With annual throughput more than 5, 000 sets, our products are sold not only in China but also oversea such as India, Pakistan, Vietnam, Malaysia, Singapore, Russia, Australian, America, Romania, Bulgaria and South Africa, etc.
