1. WCB, LCB, low carbon steel and alloy steel, stainless steel available
2. Rich experience in materials ASTM WCB, LCB, low carbon steel and alloy steel. Stainless steel
3. Professional tooling and process to reduce cost.
4. Excellent surface and inner quality.
5. Electric furnace and strict chemical composition test before cast.
1. Why choose investment casting?
1). Investment castings have high dimensional accuracy, general linear tolerance is 1%,
The angle tolerance is ± 0.5° , good surface finish, up to Ra 1.6-3.2, to save materials
& reduce machining cost.
2). Investment casting can produce parts or components with complex shapes, or cast
Several parts into one whole, to avoid combination or welding.
3). Beautiful text or LOGO images can be cast on the products to improve the image
Of your products.
4). The performance of materials for investment casting are very extensive, wear-resistant,
Heat-resistant and corrosion- resistant, the hardness of the material up to HRC15-60,
To meet the demands of different industries.
5). Investment casting approved flexible production volume, from a small number to high-
Volume production, high efficiency and good reproducibility; Low-cost mold, less input
In the early product development.
| Quality System certificate | ISO9001 |
| Dimension Tolerance | CT7 |
| Surface Roughness | Ra6.4-12.5 |
| Casting weight | 0.05-500kg |
| Annual Production Capability | 8000Tons per year |
| Inspection | 1.Chemical Composition Analysis 2.Tensile Test 3.Dimension Inspection
4.Hardness Testing 5. Ultrasonic 6. Magnetic Particle Inspector
7. Three Coordinate Measuring Machine
8. Metallographic Examination Instrument, etc |
| Material | Carbon Steel, Low Alloy Steel,Ductile Iron, Grey Iron, alloy cast iron ect |
| Surface Treatment | Heat Treatment, Machine, Polishing, Chrome, Zinc, Nickel Plating |
| Casting Techniques | 1.Lost Wax Casting, 2.Lost Wax & Foam Casting 3.Sand casting |
| Sales Percentages | 1. Auto Casting Parts -- 35%
2. Casting Forklift parts -- 20%
3. Railway & Train Casting Parts -- 20%
4. Construction Machinery Casting Parts -- 10%
5. Marine and railway Parts -- 10%
6. Other Casting Parts -- 5% |
| Market Percentages | 1. Europe -- 40%
2. North America -- 35%
3. Asia -- 15%
4. Domestic Market -- 10% |
| Advantage | 1.More than 20 years experience
2.15-20 days delivery after deposit
3.Special Analysis of raw material and liquid melt,match before casting
4.Control spectral and thermal analysis equipment
5.Passed ISO 90001 |
Qingdao Chifine Machinery Co., Ltd is One Famous Company in China Which Specialized in Various Metal Casting Products with Over 10 Years Experience Located in Qingdao China. It Covers a Comprehensive Range of Forging, Stamping, Sand Casting, Investment Casting, Die Casting and Machining and Was Widely Used in Agriculture Machinery, Motor Vehicle, Architecture, Railway and Engineering Chifine Has Accumulated Important and Valuable Experience in Design, Manufacturing and Customer Service Over These Years We Will Continue to Integrate Our Technical Superiority, Improve Process and Quality to Increase Market Share and Create More Brilliant Future.
Automative Casting Line:
• Material: Grey iron(GG20-GG35); Ductile iron(GGG40-GGG60);
Malleable cast-iron(GTS35-10/45-06/55-04/65-02, CTW35-04/05/06/07).
• Product Size: 0-1000mm.
• Weight: 0.2kg-100kg
Resin Sand Casting
• Material: Grey iron(GG20-GG35); Ductile iron(GGG40-GGG60);
Malleable cast-iron(GTS35-10/45-06/55-04/65-02, CTW35-04/05/06/07).
Steel casting(ASTM/UNS; DIN; JIS; NF; BS; ISO)
• Product Size: 0-1500mm.
• Weight: 10kg-5000kg
Shell Mould Casting
Shell casting is one of resin sand casting process.
It is suitable for thin-wall casting parts, be free from porosity.
• Material: Grey iron(GG20-GG35); Ductile iron(GGG40-GGG60);
Malleable cast-iron(GTS35-10/45-06/55-04/65-02, CTW35-04/05/06/07).
Steel alloy; Aluminum alloy; Copper alloy.
• Product Size: 0-500mm.
• Weight: 50g-100kg.
• Wall thickness: 4-20mm
Lost Wax Casting
• Advanced wax-injection-machine and tool to ensure accurate wax-patten.
• Stable temperature and humidity environment make the wax-patten no deformation.
• Material:
Carbon steel; Stainless steel; Alloy steel.
Grey iron(GG20-GG35).
Ductile iron(GGG40-GGG60);
Malleable cast-iron
(GTS35-10/45-06/55-04/65-02, CTW35-04/05/06/07).
Aluminum alloy; Copper alloy.
• Casting size: 0-500mm.
• Casting weight: 50g-100kg
Stamping and Forging Line
• Stamping and forging equipment: 16T-300T press machine
• Automatic transport forging line
• Material: Carbon steel; Stainless steel; Alloy steel.
Aluminum alloy; Copper alloy.
Machining Shop
Our machining shop located in Qingdao, using the latest CNC equipment to provide our customer with high quality products.
• Horizontal and Vertical Machining Center
• CNC lathe and normal lathe
• CNC drilling and milling Center
• Other assistant equipment
