Liquid Sanitary Centrifugal Pump

Liquid Sanitary Centrifugal Pump
Price: US $ 200set
Trade Terms: FOB,CFR,CIF
Min Order: 1set
Pay Type: L/C,T/T,D/P

Applications
Our pump is a highly efficient and economical centrifugal pump, which meets the requirements of sanitary and gentle product treatment and chemical resistance. It is available in nine Sizes, KS-5, -10, -15, -20, -25, -30, -35, -40, -45...

Standard design
Our pump consists of a standard motor, stub shaft, mechanical compression coupling (KS-5 with pin bolts), adaptor, back plate, impeller, pump casing and shaft seal. Our pump is designed for CIP withemphasis on large internal roundings and cleanable seals. The sanitary stainless steel cover for protection of the motor, and the complete unit is supported on four adjustable stainless steel legs and Shaft seals. The pump may also be equipped with a double mechanical shaft seal.

Features:

Motor: 0.55-22Kw(KS)
Impeller: Open type(KS)
R/minjkl speed: 2900rpm(50Hz)
3600rpm(60Hz)
Flow: 1.5-120m3/h(KS)
Lift: 75m(KS)

MAX pressure: 7Bar(Ks)
MAX temperature: 120°C/248°F
Connection: Clamp, Thread, Flange, Welding
Standard: DIN, SMS, 3A, ISO, IDF, RJT

Design and Standard:
Design based on 3A hygienic standard
Adjustable stainless steel leg
Mechanical seal: single mechanical seal
Flushed single mechanical seal
Flushed double mechanical seal

Material:
Motor housing: Cold rolled stainless steel plate
Investment casting impeller: AISI 304/316L
Contact parts with material: Viton, EPDM
Gasket: SSC-Sic/EPDM
Internal surface: Ra≤0.8um
External surface: mirror polish



Technical data:





  STRUCTION:







FLOW CHART:








Prod Model: DY-P-10
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Impeller: Open Impeller (New Design)
Mechnical Seal: Mechnical Seal
Motor: ABB/Siemens/Chinese Brand
Connection: Weld/Clamp/Thread/Union
Motor Cert: UL Motor
Pump Cover: Square/Round
Working Pressure: Low Pressure Pump
Position Of Pump Shaft: Horizontal Pump
Impeller Number: Single-Stage Pump
Influent Type Of Impeller: Open Impeller
Wenzhou DeYi Machinery is a high-tech science and technology enterprise which integrates design, development, manufacture, installation and provides complete turnkey project. Specializing in the manufacture and sale of bio-pharmaceutical, food, dairy, beer and beverage engineering equipments and various sorts of pressure vessels and non-standard equipment to meet the needs of users, such as stainless steel tanks, Chinese medicine extractors, concentration and evaporation equipment, alcohol recovery equipment, online CIP cleaning equipment, stainless steel pipe, sheet, valves fitting and so on. We always pursue the goal of "excellence and innovation". We research and develop new processes and designs so as to comply with cGMP and FDA requirements.

"Quality first and customer first" is our tenet. Our goal is simply to furnish high quality products at competitive prices in the global market and delivering to meet the challenges required in the today's business environment. We sincerely welcome friends from around the world to cooperate with us to have a brilliant future.

Choose DeYi, will get better price, good service and profit!
