LB-XF Cyclone Dust Collector for the pre-filtration system
The preprocessor is cyclone dust removal device. Simple design and structure, adopting axial and central inlet type.
Uniform air distribution, cyclone cylinder external spiral line bypass separation chamber, dust tangent air into a cylinder spiraling flow, along the wall and bypass the separation chamber downward movement, due to centrifugal force role will dust separation, used to remove larger dry density of fibrous dust, dust removal efficiency can reach 85-95%.
reasonable design structure is simple
good for the settlement of large particles and capture spark
used in dust cleaning system of the primary filter
Applications:
Smelting, casting, sand blasting, building materials and refractory materials and other industries,
Used for the coarse material level dust collection and dust removal system.
Technical parameters:
Model | Airflowm3/h | Specification(Diameter*H)mm |
LB-XF2500 | 2000-3000 | φ700*2600mm |
LB-XF4000 | 3001-5000 | φ800*2800mm |
LB-XF7000 | 5001-8000 | φ900*3000mm |
LB-XF10000 | 8001-12000 | φ1000*3200mm |
LB-XF13000 | 12001-15000 | φ1100*3300mm |
LB-XF17000 | 15001-20000 | φ1200*3500mm |
LB-XF22000 | 20001-25000 | φ1200*3700mm |
LB-XF30000 | 25001-32000 | φ1300*4000mm |
Company Infomation:
We,Qingdao Loobo Environmental Protection Technology Co.,Ltd is aimed to air purifying and kinds of removing fume exhausted, with its own R&D team more than ten years manufacturer, located in Qingdao city of china, specialized in the main products:
1,portable fume extractor,
2.downdraft benches(grinding dust removal worktable),
3.central fume purification projects,
4.Spare parts:flexible suction arm,etc.
All of our products with the ISO9001, and CE certification for parts of products, the quality can be guaranteed.
