Performances & Characteristics
1. The pneumatic friction clutch and brake realizes stable connection, less friction and longer lifespan;
2. The electric PLC control system is with standard inching, single-circulation and continuous operation modes;
3. The sliding block is equipped with pressing safety device which will collapse due to overloading to protect the machine from being damaged.
4. The machine takes the advantages of strong universal property, high precision, reliable performance and easy operation.
5. The machine is equipped with automatic feeding device, which realizes automatic punching operation.
|
TECHNICAL PARAMETERS |
JH21-63 |
JH21-80 |
JH21-100 |
H21-125 |
JH21-200 |
JH21-315 |
JH21-400 |
|
NOMINAL PRESSURE (KN) |
630 |
800 |
1000 |
1250 |
2000 |
3150 |
4000 |
|
Nominal Pressure stroke (mm) |
4 |
4.5 |
5 |
5 |
6 |
6 |
6 |
|
RAM STROKE (mm) |
100 |
120 |
140 |
160 |
200 |
220 |
220 |
|
IMES OF STROKE (times/min) |
50 |
50 |
50 |
50 |
40 |
38 |
38 |
|
MAX DIE INSTALLATION HEIGHT (mm) |
270 |
300 |
320 |
370 |
450 |
500 |
500 |
|
REGULATION OF DIE INSTALLATION HEIGHT (mm) |
70 |
80 |
90 |
100 |
110 |
120 |
120 |
|
CENTEROF RAMTO MACHINE BODY (mm |
270 |
300 |
350 |
360 |
430 |
500 |
500 |
|
WORKTABLE SIZE (front-rear×left-right)mm |
470×750 |
570×860 |
650×1000 |
700×1100 |
840×1400 |
940×1700 |
940×1850 |
|
WORKTABLE HOLE SIZE (mm) |
Φ160 |
Φ160 |
Φ160 |
Φ160 |
Φ200 |
Φ250 |
Φ250 |
|
WORKTABLE THICKNESS (mm) |
80 |
90 |
110 |
120 |
180 |
200 |
200 |
|
RAM BOTTOM SURFACE SIZE (front-rear×left-right)mm |
400×480 |
430×560 |
480×580 |
520×620 |
650×880 |
720×1000 |
720×1000 |
|
DIE HANDLE HOLE SIZE (diameter×depth)mm |
Φ50×60 |
Φ60×80 |
Φ65×80 |
Φ70×80 |
Φ70×100 |
Φ70×100 |
Φ70×100 |
|
COLUMN DISTANCE (mm) |
560 |
590 |
640 |
640 |
820 |
1050 |
1050 |
|
MOTOR (model /power)KW |
Y132S-4/5.5 |
Y132M-4
/7.5 |
Y132M-4
/7.5 |
Y160L-6/11 |
Y180L-
6/15 |
Y225M-
6/30 |
Y250M-6/37 |
|
OUTLINE DIMENSIONS (front-rear×left-right×height)mm |
1615×1200
×2570 |
1915×1385
×2820 |
2100×1390
×3000 |
1900×1400
×3350 |
2370×1600
×3600 |
3400×1950
×4100 |
3800×2200
×4300 |
|
WHOLE MACHINE WEIGHT (Kg) |
5500 |
7500 |
9200 |
9800 |
19500 |
34700 |
43000 |
