Specifications
1 honey brass recyling turnkey plant
2 machinery and technique support supplier
3 low budget, environment friendly
Introduction and structure
Melting furnace and holding furnace are tied together. No smoke furnace itself while melting. Auto constant temp control unit is available. Widely used in the field of brass, copper alloy products.
Both furnace connect through bottom, raw material melted down, liquid can be flowed to holding furnace chamber after component of liquid met special requirement. We this design structure can reduce smoke, loss of zinc because of oxidizing. Energy consumption is less.
The 120kw, 75kw main frequency cored induction furnace is composed by furnace body, inductor, cabinet, the inductor is installed under furnace body, include iron core, copper loop, coil, water jacket and so on.
1 75kw melting furnace + 75kw holding furnace
Specification:
Model: 300
Power: 75+75(kw)
Melting rate: 300kg/h
Capacity: 1+1.8(ton)
Quantity: 1 unit
2 Die casting machine
Specification:
Model: SYO-60
Speed: 0-0.035m/s
Casting diameter: 5-60mm
Quantity: 2 set
3 Pneumatic sawing machine
Specification:
Model: Q60
Cutting size: Φ 5-60mm
Speed: 10s/pcs
Power: 3kw
Air pressure: 0-1 Mpa
Quantity: 2 set
4 Heading machine
Specification:
Model: CZ-A
Heading size: Φ 5-20mm
Heading length: 50-120mm
Cutter: 4 set
Motor power: 2.2kw
Quantity: 1 set
5 Heading machine
Specification:
Model: CZ-C
Heading size: Φ 15-60mm
Heading length: 50-120mm
Cutter: 4 set
Motor power: 4kw
Quantity: 1 set
6 Chain type double peeling machine
Specification:
Model: LG-250(A)(B)
Peeling size: Φ 5-15mm
Working length: 3m
Speed: 0.4m/s
Power: 5.5kw
Quantity: 1 set
7 Peeling machine
Specification:
Model: 5T
Peeling size: Φ 15-60mm
Working length: 3m
Speed: 15-25m/min
Power: 18.5kw
Quantity: 1 set
8 Hexagon straightening machine
Specification:
Model: YT-11C
Straightening size: S10-40mm
Precision: 0.2mm/100mm
Motor power: 5.5
Quantity: 1 set
Our company, founded in 1994, is located in Foshan City, Guangdong Province, in the Pearl River Delta of Nanhai. Our factory covers a building area of 4000 square meters, with all kinds of mechanical processing equipment. Engaged in research and development, we are a professional manufacturer of many kinds of copper rod, brass and lead casting machines, straightening machines, straightening and polishing machines, hydromatic drawlooms, copper and aluminum melting furnaces, temperature holding furnaces and other production equipment. Our company regards environmental protection, energy conservation, and non-pollution as the important index of electric furnace production equipment. We provide price inquiries, technical consultation, training, maintenance and reasonable equipment matching guidance for a new copper factory.
After several years' effort, our factory has developed the following new equipment: Conveyor belt multiple absorbing iron machines, vibration absorbing iron machines, high efficiency low loss combo furnaces, vertical type double acting lead casting machines, automatic peeling machines (no need for heading), automatic combined drawing machines, copper ash cleaning re-blowing production lines, aluminum casting machines, and vacuum casting heading machines for profiled rods (one-time heading).
Our factory always adheres to the principle of "improvement, inspiring innovation, quality first, customer first", and is dedicated to the general customer service with high quality services and low prices. We welcome clients from at home and abroad to come to negotiate business with us. We are willing to work with you.
