Specifications
Option: C45, 39NiCrMo3, 40CrNiMoA, SAE 4320, 36Mn5
Surface: Machining
Forged shaft
OEM
FORGING THE FUTURE, WE DO THE BEST
OUR COMMITMENT: COMPETITIVE PRICE, HIGH QUALITY AND GOOD SEVICE
High quality rotary forged CRANKshaft:
Specification:
1: Processing high quality gear
2: Materials: C45, 39NiCrMo3, 40CrNiMoA, SAE 4320, 36Mn5
3: Measurement: Max outside dia: 3200, weight: 30 tons.
Detail description:
1: Name: Gear shaft
2: Proces: Heat forging
3: Certificates: ISO9001-2000, SGS
4: Products ability: Max length: 1--16m, Max OD: 3m
5: Surface: Polishing or per costomer's requirement
Products range:
Die Forging, Main Shaft, Wind Power Shaft, Stabilizer, Flange, Coupling, BOP Body, Tube Plate, Roller Forging, Roller Shell, Ring Forging, Gears, Gear Blank, Gear Shaft, Gear Wheel.
| Structure: | step shaft | Material: | Steel,35CrMo,1.7220 | Coatings: | Black Oxide |
| Length: | max.12000mm | Model Number: | SFHW02-212 | Place of Origin: | Shaanxi China (Mainland) |
| Brand Name: | JINHUAWEI | Forging part: | 42CrMo Alloy Steel Forged Step Shaft | Application: | Explosion-proof Motor |
| Inspection: | the third party, in house | Delivery condition: | rough machining,finish machining | Certification: | ISO9001:2008;BV;ABS |
| Standard: | GB,JIS,AISI,SAE,ASTM,EN,DIN | Forging ratio: | greater than 4.5 | Steel ingot: | EAF-LF-VD/ESR |
| UT test: | DIN EN 10228 |
Packaging & Delivery
| Packaging Detail: | Forging parts: rust resistant, nylon strap, steel strip and wooden pallets or wooden case |
| Delivery Detail: | 30~60days |
Specifications 1. 42CrMo Alloy Steel Forged Step Shaft
2.100% UT test
3.Mechanical property test
4.Nonstandard
Product Description
| Forging part | 42CrMo Alloy Steel Forged Step Shaft |
| Material | 35CrMo,1.7220 |
| Dimension | Dia.:100~2000mm;Length:Max.12000mm |
| Application | Explosion-proof Motor |
| Inspection | chemical composition;UT,MT; mechanical property;dimension check |
| Standard | ASTM, ASME, DIN, JIS, ISO, BS, API, EN |
| QC Doc. | chemical composition report;mechanical properties report;UT test report; heat treatment report; dimensions check report. |
| Forging processing | ingot---forging---heat treatment---rough machining---UT.MT---Q+T---inspection---finishing machining---UT.MT---packing |
| Heat treatment | Normalized / Annealed / Quenched / tempered |
We sincerely hope establishing long and friendly business relations with clients from all over the world. Our goal is not just providing product, but also providing a complete solution including product design, tooling, fabrication and service for our customers to achieve their upmost satisfaction.
Forging weight is from 50 kg to 20 ton. Many kinds of materials, free size.
Smelting Process: EF+LF + VD+VC The process as follow: Ingot → Heat → Forging → Heat treatment (Normalizing+ tempering) → Inspection → Rough machining→ UT → 2th Heat treatment → Finishing machining → Inspection
Applications: The heavy forging: Forged ring, shaft, roller, flange, or gear is widely used for various industries For example: Metallurgy, mining, power station and so on.
Specifications:
Description
The heavy forging: Forged ring, shaft, roller, flange, or gear
Material
Alloy steel or stainless steel
Material standard
ASTM or GB/T3077-1999
Specification
As per specified requirements
Weight
Max. 250 ton
Smelting Process:
EF+LF + VD+VC
Process
Ingot→ Heat → Forging → Heat treatment (Normalizing+ tempering) → Inspection
→ Rough machining→ UT → 2ND Heat treatment → Finishing machining → Inspection
UT standard
EN10228, ASTM A388 or JB/T 5000.15-1998
Competitive Advantage:
The heavy forging is manufactured by large scale stated enterprise. Advanced technical process from smelting steel to forging and heat treat guarantees the product quality. Closed relationship with several famous stated enterprises guarantee "in-time delivery" and competitive price.
Excellent product quality and service, competitive price, "in-time" delivery
