High-speed guardrail roll forming machine
Features: Leveling roller quenched and tempered, chrome treatment of its rigidity, mechanical properties such as surface roughness greatly increased; The pinch roll and by the leveling rollers, pinch rollers can be individually adjusted, leveling the overall structure of the roller, before and after the establishment of two adjustment points to a certain angle, easy to improve the quality of the school level. Leveler into the discharge end with a pair of guide rollers and two pairs of oriented flat vertical roll, vertical roll can be driven to move and also move on. Hand wheel adjustment, with a scale to facilitate the pair. Before and after leveling machine with Prime bridge device.
Features: Cutting machine in the machine end, an independent body, the rotary encoder counter fixed-length, cut length can set their own. Shears tool material with high-quality cutting tool material Cr12MOV, cut mouth, and no edges longer tool life, change fast, very convenient to adjust the shear gap.
Function and structure: Sheet metal by roll 13 times, gradually rolling into finished products. By the motor, reducer, sub-tooth gear box, universal joint, the roller group composition. The bed is the word welded structure, to stress treatment; Gear box for the 180 plus large; Roll imported process design software, computer design, and FEA analysis to ensure the accuracy of the workpiece shape. Roll with GCr15 forging, CNC machining overall quenching, the hardness can reach HRC58-62; With high strength, high hardness, high-precision, life and other characteristics.
The whole line using PLC control, liquid crystal display touch screen, user interface. The interaction between man and PLC. Operator to run automatically by setting the program (programmable control) to monitor the process and control, to achieve production line operator control and modify the control parameters, and real-time monitoring equipment operating status, operating parameters and fault indication and so on. Workpiece length of the digital setting, adjust the length of the workpiece. Real-time monitoring equipment operation status and fault indication.
Weifang Highfull Machinery Co., Ltd is located in Weifang City, the kite capital, Shandong Province, conveniently located near Qingdao City's sea and air port, Jiqing expressways and Jiaoji railways.
Rely on the good foundation of culture and machinery, as well as our fine product quality, perfect services, we win the market and make rapid progress.
We are a high-tech enterprise of producing the steel plate cold roll forming machine, mainly dealing with Mainwhile, we are able to produce and design the cold roll forming machine according to our customers' specific requirements. With our strong technical force, in the factory, there are more than 60 sets, such as milling machine, planing machine, grinding machine, drilling machine, planer type milling machine, heat-treated furnace and so on. We have 30 high-ranking technicians and engineers or so. The main products includes, roller press, roll bending, forming machine, lever device, slitting machine, color steel tile equipment, C/Z shaped steel equipment, steel structure equipment, colored sheet door equipment, color section equipment, security door equipment, security door frame equipment, square and round steel tube equipment, door frame section, auto car carriage plate equipment, motorized tricycles carriage plate equipment, electrocar carriage plate equipment, container equipment, car sections, stainless steel door equipment, fire door equipment, light steel keel equipment, garage door equipment, solar energy stand equipment, goods shelf section equipment, bridge bus duct equipment, high-speed guardrail equipment, and all kinds of roll mill, roller etc. Cold bending roll forming machine.
Our company pursues progress continuous on the way to technological innovation in recent years. We set up R&D(research and development)center in Shanghai in 2006. We have developed ultrasonic sections, eddy currents etc. Nondestructive testing equipment united with Shanghai Jiaotong University and Shanghai Ligong University etc. Research institutions. We cooperate with friends of home and abroad.
