| Price: | Negotiablekg |
|---|---|
| Trade Terms: | FOB,CFR,EXW |
| Min Order: | 50kg |
| Pay Type: | L/C,T/T,D/P,Paypal |
1.Material :Grey Iron, Ductile Iron, Malleable Iron, Carbon Steel, Aluminum,Brass,Bronze, copper ,zinc, Stainless Steel(Little) etc
2.Tolling process:Resin sand/Green Sand
3.MAX unit weight:Iron sand casting 30TON ,Steel sand casting 200TON
4.Max/Min wall thickness requirements:4mm-250mm
5.Heat Treatment:Annealing, Quenching and tempering, Normalizing
6.Surface treatment:Paint,Anti-rust oil,Hot dipping galvanized,Powder coating
7.Certification:ISO9001(2008)
8.Products application:Machinery applications, automotive industry, lighting equipment, household appliances etc
9.Carbon Steel Sand Casting Fabricated Parts
| Item | Typical | Feasible |
| Shape s | Thin-walled: Complex Solid: Cylindrical Solid: Cubic Solid: Complex | Flat Thin-walled: Cylindrical Thin-walled: Cubic |
| Part size | Weight: 1 oz - 450 ton | |
| Materials | Metals Alloy Steel Carbon Steel Cast Iron Stainless Steel Aluminum Copper Magnesium Nickel | Lead Tin Titanium Zinc |
| Surface finish - Ra | 300 - 600 μ in | 125 - 2000 μ in |
| Tolerance | ± 0.03 in. | ± 0.015 in. |
| Max wall thickness | 0.125 - 5 in. | 0.09 - 40 in. |
| Quantity | 1 - 1000 | 1 - 1000000 |
| Lead time | Days | Hours |
| Advantages | Can produce very large parts Can form complex shapes Many material options Low tooling and equipment cost Scrap can be recycled Short lead time possible | |
| Applications | G ears, pulleys, crankshafts, connecting rods, and propellers, housings for large equipment and heavy machin | |
| Prod Model: | MD-QT400-18 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Delivery Time: | 15 Days |
| Process: | Lost Wax Process |
| Type: | Clay Dry Sand |
| Material: | Ductile Iron, Carbon Steel |
