High Quality Swp Cardan Shaft

High Quality Swp Cardan Shaft
Price: US $ 1-100/Piece
Trade Terms: FOB,CIF
Min Order: 1/Piece
Pay Type: L/C,T/T
SWP subdivision type bearing the cross shaft universal coupling product introduction: To facilitate replacement bearing, SWP cross axle type universal shaft coupling bearing design is split, shaft bolt, is suitable for the rolling machinery, lifting transportation machinery and other heavy machinery, connecting two different axis transmission shafting, turning diameter from 160 ~ 640 mm; 16 ~ 1250 kn m., nominal torque axis Angle A ~ F type is not more than 10 ° , G type is not more than 5 ° .
PART NO.    D    β≤    L+Lx                                                             SIZE mm
        D1 D2    D3 E E1 b×h h/2 L1 n-d
SWP160-91 160 10° 610+50 140 95 114 15 4 20×12 6 85 6-13
SWP180-91 180 10° 700+60 155 105 121 15 4 24×14 7 95 6-15
SWP200-91 200 10° 780+70 175 125 127 17 5 28×16 8 110 8-15
SWP225-91 225 10° 928+75 196 135 152 20 5 32×18 9 130 8-17
SWP250-91 250 10° 958+80 218 150 168 25 5 40×25 12.5 135 8-19
SWP285-91 285 10° 1103+100 245 170 194 27 7 40×30 15 150 8-21
SWP315-91 315 10° 1240+110 280 185 219 32 7 40×30 15 170 10-23
SWP350-91 350 10° 1400+120 310 210 245 35 8 50×32 16 185 10-23
SWP390-91 390 10° 1480+120 345 235 273 40 8 70×36 18 205 10-25
SWP435-91 435 10° 1740+150 385 255 299 42 10 80×40 20 235 16-28
SWP480-91 480 10° 1940+170 425 275 351 47 12 90×45 22.5 265 16-31
SWP550-91 550 10° 2125+190 492 320 402 50 12 100×45 22.5 290 16-31
SWP600-91 600 10° 2400+210 544 380 450 55 15 90×55 27.5 330 22-34
SWP640-91 640 10° 2700+230 575 385 480 60 15 100×60 30 350 18-38
SWP700E 700 10° 3580+250 655 570   90       420 24-26
SWP750E 750 10° 3780+250 695 610   95       460 24-33
SWP800E 800 10° 3920+250 745 650   100       480 24-33
SWP850E 850 10° 4160+250 785 680   105       530 24-39
SWP900E 900 10° 4860+300 835 710   110       555 24-39
SWP950E 950 10° 4980+300 885 760   120       580 24-39
SWP1000E 1000 10° 5150+300 925 800   125       625 20-45
SWP1050E 1050 10° 5230+300 975 840   130       645 20-45
SWP1100E 1100 10° 5330+300 1025 880   135       670 20-45
SWP1150E 1150 10° 5520+300 1065 925   140       715 20-52
SWP1200E 1200 10° 5620+300 1115 960   150       740 20-52
SWP160-87 160 12° 610+40 140 95 114 15 4 20×12 6 85 6-13
SWP180-87 180 12° 700+50 155 105 121 15 4 24×14 7 95 6-15
SWP200-87 200 12° 780+55 175 125 127 17 5 28×16 8 110 8-15
SWP250-87 250 12° 958+70 218 150 168 25 5 40×25 12.5 135 8-19
SWP290-87 290 12° 1103+85 250 170 194 27 7 40×30 15 150 8-21
SWP315-87 315 12° 1240+90 280 185 219 32 7 40×30 15 170 10-23
SWP350-87 350 12° 1400+100 310 210 245 35 8 50×32 16 185 10-23
SWP400-87 400 12° 1480+100 355 235 273 40 8 70×36 18 205 10-25
SWP450-87 450 12° 1740+120 400 255 299 42 10 80×40 20 235 16-28
SWP500-87 500 12° 1940+140 455 275 351 47 12 90×45 22.5 265 16-31
SWP550-87 550 12° 2125+155 492 320 402 50 12 100×50 25 290 16-31
Prod Model: SWP
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Stiffness & Flexibility: Flexible Shaft
Load: Drive Shaft
Axis Shape: Straight Shaft
Shaft Shape: Real Axis
Zhejiang Baochuan Transmission Machinery Co., Ltd. is located in the beautiful West Lake is Xiaoshan, is apart from the Xiaoshan International Airport and 20 kilometers away from the Hangzhou Railway Station, Xiaoshan expressway exit of the 1 km, the traffic is very convenient.

Zhejiang Baochuan Transmission Machinery Co., Ltd. is a professional engaged in design, manufacturing, sales in one of the large-scale joint-stock enterprises, specializing in the production of SWC, SWP and SWL type cross shaft universal coupling and various types of automobile, agricultural machinery, engineering machinery transmission shaft. Universal joint, drive shaft and other types of art, the product has the advantages of reasonable design, large transmission torque, high transmission efficiency, low noise, long service life, wide application range, etc...SWC, SWP and SWL type cross shaft universal coupling used in rolling mill main drive and auxiliary transmission, also suitable for hoisting machinery, mining machinery, engineering machinery, petroleum machinery, vehicle, ship propulsion system, papermaking machinery, especially for metallurgical industry technical modification and renewal of mechanical product provide strong support. The drive shaft can be used for a variety of passenger cars, trucks, agricultural machinery, engineering machinery, products to meet different customer needs for the purpose.

The company has first-class production equipment, forging, heat treatment center to center and machining center. Production equipment of various types of CNC lathe, machining center, milling machine, boring machine, broaching machine, slotting machine and the dynamic balancing machines, meet light, medium, heavy and large parts, product demand, thus forming the specialization, serialization of the production pattern, the equipment investment is in the leading position in the same industry.

The company has a number of decades of design, production and universal shaft coupling of professional talents, their rigorous work style, high business level, refine on quality requirements.

Company' S products to the quality to win, each link in the production strictly according to ISO9001 quality management system requirements of the process, and put forward the "next project (customer) satisfaction is quality assurance" slogan, continuous improvement to meet customer demand.

The company' S entrepreneurial spirit is people-oriented, winning by quality, based on domestic, international expansion. Warmly welcome new and old customers to our company to negotiate business, sincere cooperation, create brilliant.
