| Price: | US $ 950-1150/Ton |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 10/Ton |
| Pay Type: | L/C,T/T |
| Shape | Dimension(mm) | Ductile Iron Bar | |||||||
| Outsides Dimension Tolerance (mm) | |||||||||
| Round | Φ20—φ45 | 0 ~ +2.0 | |||||||
| Φ45—φ65 | 0 ~ +2.0 | ||||||||
| Φ65--φ100 | 0 ~ +2.5 | ||||||||
| φ100-200 | 0~+4.0 | ||||||||
| Grade | Chemical composition(%) | Mechnical Properties | |||||||
| C | Mn | Si | S | P | Mg | Mpa tensile Strength | hardness HB | Elongation (%) | |
| ASTM A536 65-45-12 (LZQT 450~10) | 3.2~3.9 | 0.2~0.4 | 2.2~3.2 | ≤ 0.03 | ≤ 0.1 | 0.02~0.06 | 30 ≤ D≤ 150 420~450 150≤ D≤450 400~430 | 140~200 | 30 ≤ D≤ 120 ≥ 12 125≤ D≤ 450 ≥ 8 |
| Prod Model: | Round. square and different shaped |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Ductile Iron Tolerance: | 2.5 |
| Casting Metal: | Cast Iron |
| Casting Form Material: | Metal |
| Casting Form Usage Count: | Permanent |
| Casting Method: | Horizontal Continuous Cast |
