Iterm: Round Pin Chain Shackle, G-215, S-215, Drop Forged Alloy Steel - China Manufacturers, Suppliers
Please visit our website for more infomation. Thanks!
http://www.dawson-group.com/dawsongroup/Shackles/
Galvanized or hot-dipped galvanized or self-colored.
The S. W. L. Is 4: 1 or 6: 1.
Made by Forging, Free forging.
Dawson Group supply Shackles, bow shackle, anchor shackle, trawling shackle, lifting shackle, high tensile shackle, alloy shackle, stainless shackles, chain shackle, drop forged European type, ect.
Rigging Hardware
Screw Pin Anchor Shackle G-209
Round Pin Shackle G-213
Screw Pin Chain Shackle G-210
Round PIn Chain Shackle G-215
Bolt Type Anchor Shackle G-2130
Bolt Type Chain Shackle G-2150
Alloy Steel Anchor Shackle A-209
Trawling Shackle
Trawling Shackle With Round Head Screw Pin
EU Type Large Dee Shackle Same Size Diameter Pin With Body
EU Type Large Bow Shackle Same Size Diameter Pin With Body
Trawling Shackle With Square Head Screw Pin
| ART.NO. | SIZE | W.L.L. | PIN DIA. | I.L. | N.W. |
| | inch | ton |
inch | inch | lbs |
| DSHSF1401 | 1/4" | 1/2 | 5/16 | 7/8 | 0.10 |
| DSHSF1402 | 5/16" | 3/4 | 3/8 | 1-1/32 | 0.18 |
| DSHSF1403 | 3/8" | 1 | 7/16 | 1-1/4 | 0.25 |
| DSHSF1404 | 7/16" | 1-1/2 | 1/2 | 1-7/16 | 0.38 |
| DSHSF1405 | 1/2" | 2 | 5/8 | 1-5/8 | 0.50 |
| DSHSF1406 | 5/8" | 3-1/4 | 3/4 | 2 | 1.21 |
| DSHSF1407 | 3/4" | 4-3/4 | 7/8 | 2-3/8 | 2.00 |
| DSHSF1408 | 7/8" | 6-1/2 | 1 | 2-13/16 | 3.28 |
| DSHSF1409 | 1" | 8-1/2 | 1-1/8 | 3-3/16 | 4.75 |
| DSHSF1410 | 1-1/8" | 9-1/2 | 1-1/4 | 3-9/16 | 6.30 |
| DSHSF1411 | 1-1/4" | 12 | 1-3/8 | 3-15/16 | 9.00 |
| DSHSF1412 | 1-3/8" | 13-1/2 | 1-1/2 | 4-3/8 | 12.00 |
| DSHSF1413 | 1-1/2" | 17 | 1-3/4 | 4-13/16 | 16.15 |
| DSHSF1414 | 1-3/4" | 25 | 2 | 5-3/4 | 29.96 |
| DSHSF1415 | 2" | 35 | 2-1/4 | 6-3/4 | 43.25 |
| DSHSF1416 | 2-1/2" | 55 | 2-3/4 | 8 | 72.30 |
| M.B.S. IS 6 TIMES OF W.L.L.MEET FEDERAL SPECIFICATION RR-C-271D TYPE IVB, GARDE A , CLASS 1 |
