Flange Type API Globe Valve with Standard
| Price: |
US $ 9999/Piece |
| Trade Terms: |
FOB,CFR,EXW |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,D/P,Western Union |
Product Description
Description:Flange Type API Globe Valve With Standard
Application:Petroleum, chemical industry, Pharmacy, fertilizer, and power industry etc.
Product Main Advantage:Good appearance, long service life and flexible switch Conveyance
CE, ISO9001 certificated
Standards:Design and Manufacture: Cast steel globe valve to BS 1873
And ASME B16.34, Forged steel globe valve to API 602.
Inspection and Test: API 598.
End flange dimension: ASME B 16.5.
BW end dimension: ASME B 16.25.
Socket-weld dimension: ASME B 16.11.
Face to face and end to end: ASME B 16.10.
Pressure-temperature ratings: ASME B16.34.
| Administer Standard |
| Design and Manufacture | ANSIB16.34 BSI1873 |
| Face to Face | ANSI B16.0 |
| Flange Dimension | ANSI B16.5 |
| Butt Welding Dimension | ANSI B16.25 |
| Presuure Temperature Lating | ANSI B16.34 |
| inspection and Test | API 598 |
| PressureTest |
|
| Norminal Pressure PN(Lb) | Shell Test | Water Seal Test | Air Seal Test |
| Mpa | Lbf/in² | Mpa | Lbf/in² | Mpa | Lbf/in² |
| 150 | 3 | 430 | 2.2 | 315 | 0.4-0.7 | 60-100 |
| 300 | 7.7 | 1110 | 5.7 | 815 |
| 600 | 15.3 | 2220 | 11.3 | 630 |
| 900 | 23 | 3330 | 17 | 2445 |
| 1500 | 38.4 | 5560 | 28.2 | 4080 |
| 2500 | 64 | 9255 | 47 | 6790 |
| Main Part Material and Property |
| Body Cover Disc | Stem | Sealing Face | Sealing Shim | Packing | Working Temperature(ºC) | Suitable Medium |
|
| WCB | 2Cr13 | 13Cr STL With Body Material PTFE Nylon | 13Cr/Enhanced Flexible Graphite 1Cr13/Flexible Graphite SFB-2 08 Soft Steel F304 F316 F304L F316L | Flexible Graphite Enhanced Flexible Graphite SFB/260 SFP/260 PTFE | ≤425 | Water Steam Petroleum Products |
| WC1 | 38CrMoAI 25Cr2MoV | ≤450 |
| WC6 | ≤540 |
| WC9 | ≤570 |
| C5 C12 | ≤540 |
| CF8 | F304 | ≤200 | Nitric acid Acetic acid Urea |
| CF8M | F316 |
| CF3 | F304L |
| CF3M | F316L |
Specication about Flange Type API Globe Valve :
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Structure: |
Through Way Globe Valve |
| Sealing Form: |
Gland Packings Globe Valve |
| Stem Thread Position: |
Outside Screw Stem Globe Valve |
| Application: |
Bellows Globe Valve |
| Standard: |
API |
Zhejiang Jinpu industry Co., Ltd., located in the name of "Pump & Valve" hometown, Our company enjoy good reputation in the valve industry and cover more than 20000 square meters, registered capital of 50 million RMB, there are more than 120 staffs, 30 professionals, 12 engineers, which are the reasons of becoming the one of leading manufacturers in the China.
Quality assurance depends on advanced equipment, such as vertical lathe, high-performance horizontal machining center, numerically-controlled machine, drilling machine, welding machine & test machine etc; Our company is fully equipped with them.
API valve: Ball valve, gate valve, check valve & globe valve is our company main product, Up to now, our company's products are acceptable for worldwide customer, just like, USA, Japan, Europe & Middle East etc;
In order to offer our customer better service, our boss always need all of the staffs to say something advice of improvement and respond customer's demand instantly. In the meantime, a piece of words always keep us in mind, "Golden quality, Sailing around the world'. Welcome to visit us, our valves are your best choice!
