This YWT series hydraulic elbow cold forming machine is designed and constructed for cold forming small radius stainless steel elbow with curvature of 1.0D to 1.5D and with diameter from 3/4"to 20" These elbows are widely used in the connection of the industrial pipeline for the petrochemical, gas and oil pipes, electrical power, food, etc.
Featurer:
1)It is constructed with strong metal frame with good appearance and stable functioning.
2)It has individual power construction and electrical system, adopts PLC button centralized control, which can be conveniently adjusted and operated both manually and automatically.
3)The rejecting and despoiling devices are good features of our forming machines, which make the mould changed easily.
|
MODEL |
SD4-8" |
SD10-16" |
|
Clamping Capacity (KN) |
2500 |
5000 |
|
Pressing Stroke(MM) |
3150 |
4500 |
|
Hudraulic System Max Pressure (Mpa) |
31.5 |
31.5 |
|
Hudraulic System Working Pressure (Mpa) |
25 |
25 |
|
Clamping Moving Girder Stroke (MM) |
650 |
1100 |
|
Moving head Stoke (MM) |
650 |
900 |
|
Working Table Size (MM) |
1100x600 |
2000x1300 |
|
Moving Head Center Height(MM) |
135 |
260 |
|
Moving Head Speed(MM/S) |
12 |
10 |
|
Power(KW) |
18.5 |
35 |
|
Size(MM) |
3350*1200*3700 |
4700*1500*5500 |
|
N. W (t) |
18 |
38 |
Wenzhou Shunerda Pipe Fitting Equipment Co., Ltd specializes in supplying all kinds of pipe fitting machines and moulds. Our products include elbow cold forming pressing machines, tee cold forming machines, tee beveller machines, elbow beveller machines and common four column hydraulic presses.
With advanced production techniques and strict quality control, we not only enjoy a large domestic market, but also export our products to many overseas countries and regions, such as Turkey, India, Russia, Egypt and some African countries. For the purpose of providing better after-sales services for overseas customers, we have established our after sales office in different country. We guarantee to supply high quality products with reasonable prices and excellent services.
We warmly welcome customers to contact us and visit our factory. For any more detail information, pls feel free to contact with us.
